VRK Series 22 Inch Wide Rack - VRK-44-31H
22-inch wide 44RU broadcast enclosure with seismic certification, a locking rear door, and built-in lacing bars
The Middle Atlantic VRK-44-31H is a 22-inch wide, 44RU floor-standing rack designed specifically for broadcast and high-density AV environments. This robust enclosure features a fully welded construction to support a massive 10,000 lbs weight capacity. It is built to meet seismic standards, offering a seismic load capacity of 740 lbs (335.7 kg) and an ASCE 7-10 rating. The rack includes standard front and rear adjustable 10-32 threaded rackrails with numbered spaces to assist in component placement. For cable management, built-in horizontal lacing bars are positioned on 7" centers, facilitating quick "tie-and-slide" lacing for video cable bundles. The unit provides a usable height of 77 in (195.6 cm) and a usable depth of 29 in (73.7 cm). This TAA compliant enclosure is finished in a textured black powder coat and includes a partially vented locking rear door for secure equipment access. For larger installations, multiple VRK units can be gangable together when fully loaded.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Depth | 31.4 in (79.8 cm) |
| Height | 83.14 in (211.2 cm) |
| Rack Units | 44 RU |
| Shipping Weight | 168 lbs (76.2 kg) |
| UL Load Capacity | 2500 lbs (1,134 kg) |
| Usable Depth | 29 in (73.7 cm) |
| Usable Height | 77 in (195.6 cm) |
| Weight Capacity | 10000 lbs (4535.9 kg) |
All other specifications 12
| Width | 22 in (55.9 cm) |
| Federal Ops Country of Origin | USA |
| Finish | Textured Black Powder Coat |
| Gangable | Yes |
| Rack Rail Type | 10-32 |
| Rear Door | Yes |
| Seismic Rated | Yes |
| TAA Compliant | Yes |
| UPC | 656747023620 |
| ASCE Number | 7-10 |
| Certifications | TAAUL Listed |
| Seismic Load Capacity | 740 lbs (335.7 kg) |
Resources
You'll need these with it
44 RU Rackrail 10-32 for MRK/VRK Series
MV-RR44$225.00
Select Series PDU with RackLink™, 2 Outlet
RLNK-215$429.30
44 RU Cable Chase, 31 Inches to 32 Inches Deep for MRK,WRK,VRK Racks
CC-44-312$336.60
Select Series PDT Low Profile Vertical Power Strip with Dual Circuit, 10 Outlet, 20A Hardwired
PDT-2X520$418.50
Power Strip, 24 Outlet, 30A, 2 Circuits Twistlock Plug
PD-2X1215TL-30CB$1,429.20
USC Universal Sequencing Controller 1 Space Sequencing Controller
USC-6R$1,044.90
Select Series UPS Backup Power Systems - UPS-SRBP-500
UPS-SRBP-500$351.00
MPR Module 15A, Controlled Stand-Alone
RLM-15-1CA$288.00
MPR Power Module 30A, L5-30R Twistlock
RLM30-L530-1$763.20
MPR Power Module 20A, L5-20R Twistlock
RLM30-L520-1$716.40
MPR Module 20A, Controlled Stand-Alone
RLM-20-1CA$306.00
Questions about this part
Will the VRK-44-31H work for seismic-sensitive environments?
Yes, this rack is seismic rated with an ASCE 7-10 rating and a seismic load capacity of 740 lbs (335.7 kg).
What is the usable space inside the VRK-44-31H?
The VRK-44-31H provides a usable height of 77 in (195.6 cm) and a usable depth of 29 in (73.7 cm).
How can I manage heavy cable bundles in this rack?
The rack features built-in horizontal lacing bars on 7" centers, designed for quick tie-and-slide lacing of video cable bundles.
Can I mount multiple VRK racks together?
Yes, the VRK series racks are designed to be gangable once they are fully loaded.
Which documents are available for submittals?
You can download the VRK Series Enclosure A&E Specification Sheet (PDF) or the 3 Part Specification (docx) for technical submittals.
