MPR Power Module 20A, L5-20R Twistlock
Stand alone MPR power distribution module featuring 20A L5-20R Twistlock input and hard-wired connection
The RLM30-L520-1 is a stand-alone power distribution module from the MPR series. This unit is designed to be used out of the box as a ready-to-use solution for various installation challenges. It features a single circuit with a 20 Amp rating. For power input, this module utilizes a hard-wired cable type to connect to your power source. This specific SKU is an MPR Stand Alone Power Distribution component, meaning it is already installed in an MPR-style enclosure and comes with an attached power cord for immediate deployment. This module is also TAA compliant and holds ETL Recognized compliance for electrical safety.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
| Amps | 20 Amp |
| Depth | 11.63 in (29.5 cm) |
| Height | 2.63 in (6.7 cm) |
| Shipping Weight | 10.1 lbs (4.6 kg) |
| Width | 3.13 in (8 cm) |
| Cable Type | Hard-Wired |
| Number of Circuits | 1 |
| UPC | 656747059797 |
| Compliance | ETL Recognized |
Resources
Questions about this part
How is the power input connected for the RLM30-L520-1?
This module uses a hard-Wired cable type to establish its connection to the power source.
Is the RLM30-L520-1 suitable for government contracts?
Yes, this power module is TAA compliant.
What is the amperage rating of this MPR module?
The RLM30-L520-1 is rated for 20 Amp service.
Does this module work within the MPR raceway system?
Yes, these remote power modules are designed to fit within MPR raceways.
What documentation is available for installation and submittals?
You can access the RLM Series Instruction Sheet, the 30 Amp Power Instruction Sheet, or the MPR Series A&E Specification Sheet for technical details.
