RPA Elite with Lock C (1st Generation Interface Technology)-RPMCOW
White ceiling projector mount featuring Lock C quick-release, Centris positioning, and independent roll, pitch, and yaw adjustments
The Chief RPA Elite with Lock C (1st Generation Interface Technology) RPMCOW provides a secure and highly adjustable ceiling installation for universal projector mounting. This white-finish mount utilizes Centris Technology to allow for effortless fingertip positioning, automatically adjusting to support varying projector weights. For precision alignment, Microzone Adjustments facilitate fast registration, even in flush mount scenarios. The integrated Q-Lock Quick Release Lever, featuring an integrated key and lock system, allows for rapid projector disconnection for service or filter changes while maintaining security. This model provides independent roll, pitch, and yaw adjustments for exact placement. For cable management, the mount includes integrated routing to keep installations tidy without needing extra accessories. This ceiling-applied solution supports a weight capacity of 50 lbs (22.7 kg).
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
| Shipping Dimensions | 13.25" x 13.25" x 3"(336.6 x 336.6 x 76.2 mm) |
| Shipping Weight | 6 lbs (2.7 kg) |
| Weight Capacity | 50 lbs (22.7 kg) |
| Adjustability | Independent Roll-Pitch-YawMicro-Adjustable |
| Application | Ceiling |
| Color | White |
| Interface Type | Universal |
| Locking Type | C |
| Solution Type | Universal |
| TAA Compliant | No |
| UPC | 841872143170 |
Resources
You'll need these with it
Single Electric Outlet Coupler
CMA502$80.80
C-Clamp
CMA362$135.20
I-Beam Clamp
CMA360$318.40
1.5 Inch to 1 Inch NPT Adapter
CMA151$29.60
Heavy Duty Swivel Adapter
CMA351$164.00
Internal Joist Ceiling Kit
CMA165$146.40
Truss Clamp
CMS380$138.40
Dual Electric Outlet Coupler
CMA504$106.40
2' x 2' Above Suspended Ceiling Storage Box and column drop with 2-Gang Filter & Surge
CMS492CP2$945.60
Extension Column and Ceiling Mount Kit
CMS443$164.80
2' x 2' Above Suspended Ceiling Storage Box with 2-Gang Filter & Surge
CMS492P2$827.20
SpeedConnect Above-Tile Suspended Ceiling Kit with 2-Gang Filter & Surge
CMS440P2$400.80
Questions about this part
How do I service the projector once it is mounted?
The Q-Lock Quick Release Lever allows you to quickly disconnect the projector for lamp or filter access without losing your preset adjustments.
Can I adjust the projector's position after it is installed?
Yes, the mount features Microzone Adjustments for precise registration and Centris Technology for fingertip positioning, along with independent roll, pitch, and yaw.
What is the weight capacity of the RPMCOW?
This mount is rated for a weight capacity of 50 lbs (22.7 kg).
What accessories are needed for specialized ceiling mounting?
Depending on your installation, you may need accessories such as the CMA165 Internal Joist Ceiling Kit or the CMS443 Extension Column and Ceiling Mount Kit.
Does this mount include cable management?
Yes, it features integrated cable management so you do not need to purchase additional accessories for cable routing.
