Mini RPA Projector Mount (mount only)-RSA000W
White ceiling-mounted projector mount assembly for smaller projectors, featuring independent roll, pitch, and yaw adjustments
The Chief RSA000W is a compact projector mount assembly designed for smaller projectors, providing a footprint that is 1/3 the size of the standard RPA series. This white-finish unit is the top assembly only and requires a separate interface bracket to complete the installation. For universal applications, the SLBUW interface bracket is required, though users should consult Chief's MountFinder™ to identify the specific model required for their projector. This mount offers independent roll, pitch, and yaw for precise projector registration and quick connection/disconnection, allowing for easy access to lamps and filters without losing preset adjustments. Installation is versatile, supporting flush ceiling mounting, 0.25" threaded rods, or a 1.5" NPT column. For added security, all connection points utilize All-Points Security steel-into-steel locking hardware to protect against theft.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
| Shipping Dimensions | 13.25" x 13.25" x 3"(336.6 x 336.6 x 76.2 mm) |
| Shipping Weight | 5 lbs (2.3 kg) |
| Weight Capacity | 25 lbs (11.3 kg) |
| Adjustability | Independent Roll-Pitch-Yaw |
| Application | Ceiling |
| Color | White |
| Interface Type | Mount only |
| TAA Compliant | No |
| UPC | 841872119724 |
| Certifications | UL Listed |
Resources
You'll need these with it
Single Electric Outlet Coupler
CMA502$80.80
C-Clamp
CMA362$135.20
I-Beam Clamp
CMA360$318.40
1.5 Inch to 1 Inch NPT Adapter
CMA151$29.60
Heavy Duty Swivel Adapter
CMA351$164.00
Internal Joist Ceiling Kit
CMA165$146.40
Truss Clamp
CMS380$138.40
Dual Electric Outlet Coupler
CMA504$106.40
2' x 2' Above Suspended Ceiling Storage Box and column drop with 2-Gang Filter & Surge
CMS492CP2$945.60
Extension Column and Ceiling Mount Kit
CMS443$164.80
2' x 2' Above Suspended Ceiling Storage Box with 2-Gang Filter & Surge
CMS492P2$827.20
SpeedConnect Above-Tile Suspended Ceiling Kit with 2-Gang Filter & Surge
CMS440P2$400.80
Questions about this part
What is included with the RSA000W?
This is the top assembly only. To complete your installation, you must purchase a separate interface bracket, such as the SLBUW universal bracket, or the specific model identified via Chief's MountFinder™.
Can I adjust the projector once it is mounted?
Yes. The mount features independent roll, pitch, and yaw adjustments to allow for quick and precise projector registration during installation.
How much weight can the RSA000W support?
The RSA000W has a weight capacity of 25 lbs (11.3 kg).
What are the installation options for this ceiling mount?
The unit supports multiple mounting methods, including flush mounting directly to a ceiling, using 0.25" threaded rods, or attaching to a 1.5" NPT column.
Is the RSA000W security rated?
The mount utilizes All-Points Security steel-into-steel locking hardware at all connection points to help protect the installation against theft.
