Mini Elite Projector Mount (mount only)-RSMA000W
Ceiling mount for small projector models featuring micro-adjustable roll, pitch, and yaw in a white finish
The RSMA000W is the top assembly only for the Chief Mini Elite series, specifically engineered for smaller projector models. This white ceiling mount provides the same advanced adjustment capabilities as the larger RPA Elite series but in a significantly smaller form factor. It is designed to offer precision through independent micro-adjustable roll, pitch, and yaw, allowing for fine-tuned alignment once the projector is positioned. The pitch adjustment provides a 15° range. Please note that this SKU is the mount assembly only; to complete the installation, you will need to select the appropriate interface bracket for your specific projector, such as the SSMUW universal bracket, or use Chief's MountFinder™ to identify the correct model.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Shipping Dimensions | 9" x 9" x 3.5" (228.6 x 228.6 x 88.9 mm) |
| Shipping Weight | 1.91 lbs (0.9 kg) |
| Weight Capacity | 25 lbs (11.3 kg) |
| Adjustability | Independent Roll-Pitch-YawMicro-Adjustable |
| Adjustments | Pitch: 15° |
| Application | Ceiling |
| Color | White |
| Interface Type | Mount only |
All other specifications 5
| Locking Type | A |
| Solution Type | Universal and Custom |
| TAA Compliant | No |
| UPC | 841872119786 |
| Certifications | UL Listed |
Resources
You'll need these with it
Single Electric Outlet Coupler
CMA502$80.80
C-Clamp
CMA362$135.20
I-Beam Clamp
CMA360$318.40
1.5 Inch to 1 Inch NPT Adapter
CMA151$29.60
Heavy Duty Swivel Adapter
CMA351$164.00
Internal Joist Ceiling Kit
CMA165$146.40
Truss Clamp
CMS380$138.40
Dual Electric Outlet Coupler
CMA504$106.40
2' x 2' Above Suspended Ceiling Storage Box and column drop with 2-Gang Filter & Surge
CMS492CP2$945.60
Extension Column and Ceiling Mount Kit
CMS443$164.80
2' x 2' Above Suspended Ceiling Storage Box with 2-Gang Filter & Surge
CMS492P2$827.20
SpeedConnect Above-Tile Suspended Ceiling Kit with 2-Gang Filter & Surge
CMS440P2$400.80
Questions about this part
What do I need to buy to install my projector with the RSMA000W?
The RSMA000W is the top assembly only and does not include the projector interface. You must purchase a separate interface bracket, such as the SSMUW universal bracket, to connect the mount to your projector.
What is the weight capacity of the RSMA000W?
This mount supports a maximum weight capacity of 25 lbs (11.3 kg) for ceiling applications.
How much pitch adjustment does this mount provide?
The RSMA000W features a 15° pitch adjustment range to help with projector positioning.
Can I use this mount with a truss or I-beam?
Yes, the RSMA000W is compatible with various accessories including the CMA360 I-Beam Clamp and CMA362 C-Clamp.
Is this mount suitable for small-scale projector installs?
Yes, this Mini Elite version is specifically scaled down from the RPA Elite series to accommodate smaller projector models.
