1000ft (304.8m) TAA-Compliant Cat6a Bulk Shielded (STP) Ethernet Network Cable with Solid Conductors - Plenum CMP-Rated - Blue
1000ft bulk Cat6a F/UTP shielded cable, CMP plenum-rated with solid copper conductors for high-EMI environments, blue jacket
C2G56053 is a 1000 ft (304.8 m) spool of TAA-compliant Cat6a bulk shielded ethernet network cable designed for professional installations in plenum spaces. This F/UTP (Foiled Unshielded Twisted Pair) cable features solid copper conductors and a 23 AWG wire gauge to ensure high-performance data transmission. The cable is constructed with FEP (Fluorinated Ethylene Propylene) insulation and a Low Smoke Flame Retardant Polyvinyl Chloride (LSFRPVC) jacket, meeting CMP rating requirements for air-handling environments. The blue jacket helps with cable identification during complex pulls. Operating within a temperature range of -4°F to 140°F (-20°C to 60°C), this cable is engineered to minimize high-frequency noise and data errors in environments with high electromagnetic interference (EMI). This bulk cable is UL Listed and meets ANSI/TIA-568.2-D, IEC 61156-5, and ISO/IEC 11801-1 standards.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Bend Radius | 1.09 in (27.6 mm) |
| Cable Diameter | 0.27 in (6.9 mm) |
| Cable Length | 1000 ft (304.8 m) |
| Operating Temperature | -4° - 140°F (-20° - 60°C) |
| Operating Temperature Max | 140 Fahrenheit (60 Celsius) |
| Operating Temperature Min | -4 Fahrenheit (-20 Celsius) |
| Product Weight | 39.5 lbs (17.9 kg) |
| Shipping Weight | 39.73 lbs (18 kg) |
All other specifications 23
| Storage Temperature Max | 167 Fahrenheit (75 Celsius) |
| Storage Temperature Min | 68 Fahrenheit (20 Celsius) |
| Voltage | 300 V |
| Wire Gauge | 23 |
| Cable Shielding | F/UTP |
| Cable Type | BulkCat6a |
| Category Performance Application | Cat6a |
| Color | Blue |
| Conductor Material | Copper |
| Conductor Stranding | Solid |
| Connector 1 | Bare Wire |
| Connector 2 | Bare Wire |
| Connector Type | Bare Wire |
| Insulation Material | FEP (Fluorinated Ethylene Propylene) |
| Jacket Application | Plenum Rated |
| Jacket Rating | CMP Rated |
| Product Type | Cable |
| Special Features | ANSI/TIA-568.2-DIEC 61156-5ISO/IEC 11801-1 |
| TAA Compliant | Yes |
| UPC | 757120560531 |
| Certifications | CEProp 65REACHRoHSTAAUL Listed |
| Jacket Material | LSFRPVC (Low Smoke Flame Retardant Polyvinyl Chloride) |
| Warranty | Lifetime |
