Suspended Ceiling Mount for Vaddio Cameras
Suspended ceiling mount for PTZ and fixed cameras, includes one ceiling tile brace and a custom cable grommet
The 535-2000-206 is a suspended ceiling mount designed for the installation of PTZ and POV cameras in suspended ceiling environments. This mount is engineered for versatile deployment, offering compatibility with most PTZ cameras from Vaddio, Sony, Panasonic, and other major manufacturers. It is a TAA compliant solution that facilitates a clean installation by providing a specialized ceiling tile brace and a custom cable grommet to manage cabling through the ceiling tile. This mount is particularly useful for high-mounted camera placements where the camera needs to hang below the ceiling plane. The silver-finished hardware has a product weight of 2 lbs (0.9 kg) and measures 7 in (17.8 cm) in width, 7 in (17.8 cm) in height, and 26 in (66 cm) in depth. For installers requiring more specific positioning, an Offset Drop-Down Mount (535-2000-296) is available for RoboSHOT and HD-Series PTZ cameras.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Depth | 26 in (66 cm) |
| Height | 7 in (17.8 cm) |
| Product Weight | 2 lbs (0.9 kg) |
| Shipping Dimensions | 26" x 7" x 7" (660.4 x 177.8 x 177.8 mm) |
| Shipping Weight | 2 lbs (0.9 kg) |
| Width | 7 in (17.8 cm) |
| Application | Ceiling |
| Color | Silver |
All other specifications 7
| Compatible With | OtherPanasonicSonyVaddio |
| OneLINK Compatibility | No |
| Quick-Connect Compatibility | No |
| TAA Compliant | Yes |
| UPC | 840077505905 |
| Certifications | CEFCCTAA |
| Warranty | 3 years |
You'll need these with it
Verified fitment
Questions about this part
Will the 535-2000-206 fit my Vaddio camera?
Yes, it is verified to fit a wide range of Vaddio models, including the RoboSHOT 20 UHD, RoboSHOT 40 UHD, ConferenceSHOT 10, and ConferenceSHOT AV.
What cameras from other brands are compatible with this mount?
This mount is compatible with several models from Sony (such as the BRC-H700 and EVI-D100), Panasonic, and Aver (including the CAM520 and PTZ310).
Does this mount include the hardware for ceiling tile installation?
The mount includes one ceiling tile brace and a custom cable grommet to facilitate installation through a suspended ceiling.
What is the difference between this and the 535-2000-296?
The 535-2000-296 is an Offset Drop-Down Mount specifically intended for RoboSHOT and HD-Series PTZ cameras.
Which document should I use for the installation process?
You can refer to the Suspended Ceiling Mount for Vaddio Cameras Installation Guide for technical guidance during setup.
