Rackmount Power, 9 Outlet, 15A, Basic Surge Protection - 20 ft Cord
15A rackmount PDU with 9 outlets, basic surge protection, EMI filtering, and a 20 ft SignalSAFE™ power cord
The Middle Atlantic PD-915RC-20 provides reliable power distribution for professional AV racks. This 1U rackmount PDU features 9 total outlets, consisting of rear distribution outlets for organized cable management and one front-facing convenience outlet. It includes basic surge protection and built-in EMI filtering to protect sensitive equipment. To minimize potential interference from AC magnetic fields generated by other rack-mounted gear, this unit is equipped with a 20 ft (6.1 m) SignalSAFE™ power cord. The extended chassis depth of 9.63 in (24.5 cm) is designed to facilitate easier plug connection in deep enclosures. For simplified system control, a front-facing power switch allows you to toggle power to all connected equipment from the front of the rack. This ETL Listed unit operates at 120 VAC and utilizes a 5-15P plug type.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Amps | 15 Amp |
| Cord Length | 20 ft (6.1 m) |
| Depth | 9.63 in (24.5 cm) |
| Height | 1.75 in (4.4 cm) |
| Rack Units | 1 RU |
| Shipping Weight | 10 lbs (4.5 kg) |
| Volts AC | 120 VAC |
| Width | 19 in (48.3 cm) |
All other specifications 12
| Cable Type | Corded |
| Color | Black |
| Finish | Flat Powder Coat |
| Mounting Points | 2 |
| Number of Circuits | 1 |
| Outlet Count | 9 |
| Plug Type | 5-15P |
| Power Switch | Yes |
| Surge Protection Type | Basic |
| TAA Compliant | No |
| UPC | 656747103889 |
| Certifications | ETL Listed |
Resources
Questions about this part
How many outlets are on the PD-915RC-20?
The unit features 9 total outlets, including 8 rear distribution outlets and one convenience outlet located on the front.
What is the benefit of the SignalSAFE™ cord on this PDU?
The 20 ft (6.1 m) SignalSAFE™ power cord is designed to minimize potential interference caused by AC magnetic fields from other equipment in your rack.
Does this PDU include surge protection?
Yes, it provides basic surge protection and features line-to-neutral surge protection to ensure the ground remains uncontaminated.
How much rack space does the PD-915RC-20 occupy?
This power distribution unit occupies 1 RU of vertical rack space.
Can I control the power from the front of my rack?
Yes, this model includes a front-facing power switch so you can turn all connected equipment on or off from the front.
