KO Series Rear Door Fan Kit, 190 CFM & 220 - 240VAC
Rear door fan kit providing 190 CFM of active thermal management for configurable KO Series enclosures
The IKO-AWFP2 is an active thermal management solution designed for Middle Atlantic KO Series enclosures. This fan kit is intended for use with the standard solid rear doors found on WRK, MRK, and ERK Series enclosures to provide necessary airflow. The kit consists of a specialized panel and two fans, delivering 190 CFM of airflow. This specific model operates on a 220 - 240VAC input voltage, making it an international-ready component for global deployments. To install this kit, the installer must first remove the laser knockouts from the rear door. Once the knockouts are removed, the kit can be integrated into the configurable rear door to optimize heat dissipation within the rack environment.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
| CFM | 190 |
| Depth | 2 in (5.1 cm) |
| Height | 5.25 in (13.3 cm) |
| Shipping Weight | 9.1 lbs (4.1 kg) |
| Volts AC | 220 - 240 V |
| Width | 19 in (48.3 cm) |
| Available Internationally | Yes |
| Component Type | Active |
| Manufacturer | Middle Atlantic |
| Power Type | AC |
| UPC | 656747198847 |
Resources
You'll need these with it
NEXSYS™ 2 Outlet, 15 Amp Compact Power with Multi-Stage Surge Protection
PDX-215C$262.80
2 RU Select Series UPS Backup Power, 2200VA
UPS-S2200R$1,935.00
1 RU Select Series UPS Backup Power, 1000VA
UPS-S1000R$1,377.00
NEXSYS™ 9 Outlet, 15 Amp Rackmount Power with Series Surge Protection
PDX-915R-SP$907.20
Rackmount Power, 9 Outlet, 15A, Basic Surge Protection - 9 ft Cord
PD-915R$223.20
NEXSYS™ 2000VA, 20 Amp UPS Backup Power System with RackLink™, Individual Outlet Control
UPX-RLNK-2000R-8$3,850.20
Select Series PDU with RackLink™, 9 Outlet
RLNK-915R$715.50
NEXSYS™ 2000VA, 20 Amp Online UPS Backup Power System with RackLink™, Bank Outlet Control
UPX-RLNK-OL2000R-2$5,169.60
NEXSYS™ 2000VA, 20 Amp UPS Backup Power System with RackLink™, Bank Outlet Control
UPX-RLNK-2000R-2$3,519.90
Compact Premium+ PDU With RackLink™, 4 Outlet 15A & 2-Stage Surge
RLNK-P415$1,360.80
Questions about this part
Will the IKO-AWFP2 fit my Middle Atlantic enclosure?
This kit is designed to fit into the configurable solid rear doors of WRK, MRK, and ERK Series enclosures.
What is required to install this fan kit in a rear door?
Installation requires the removal of the laser knockouts from the enclosure's rear door before the panel and fans can be mounted.
What voltage does this fan kit require?
The IKO-AWFP2 operates on a 220 - 240VAC input voltage.
Does the kit include the necessary fans?
Yes, the kit includes both the fan panel and two fans to provide active thermal management.
Which document provides installation guidance?
The Rear Door Knockout Instruction Sheet provides the necessary steps for preparing the door for this kit.
