Compact Premium+ PDU With RackLink™, 4 Outlet 15A & 2-Stage Surge
Compact 4-outlet 15A PDU with RackLink™ remote monitoring, 2-stage surge protection, and slim profile for concealed installation
The RLNK-P415 is a compact Premium+ PDU with RackLink™ designed specifically to monitor digital signage installations. This 15A unit features 4 NEMA 5-15R receptacles and utilizes 2-stage MOV surge protection to safeguard sensitive displays or dvLED tiles from power anomalies. The slim form factor is engineered to be easily concealed behind displays or within dvLED tile walls. For remote management, the RLNK-P415 provides 24/7/365 connectivity to the RackLink™ Remote Management System, allowing installers to monitor everything plugged into the PDU via LAN. It is highly compatible with IT and control systems through SNMP v3/MIB, JSON-RPC, and custom drivers. For advanced environmental monitoring, the unit supports the Premium+ Series PDU Temperature and Humidity Sensor. This UL Listed and FCC certified device is HETMA approved and meets the AVIXA Energy Management Standard for efficient system design.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
| AC Voltage Input | 80-140 V |
| Amps | 15 Amp |
| Product Weight | 6.6 lbs (3 kg) |
| Shipping Weight | 6.6 lbs (3 kg) |
| Available Internationally | No |
| Outlet Count | 4 |
| Output Ports | LAN |
| Receptacle Type | NEMA 5-15R |
| Surge Protection Type | 2-Stage |
| TAA Compliant | No |
| UPC | 656747363344 |
| Certifications | FCCUL Listed |
Resources
Questions about this part
The RLNK-P415 is designed for digital signage, providing 24/7/365 connectivity via RackLink™ to monitor sensitive displays or dvLED tiles and protect them with 2-stage surge protection.
The RLNK-P415 is designed for digital signage, providing 24/7/365 connectivity via RackLink™ to monitor sensitive displays or dvLED tiles and protect them with 2-stage surge protection.
How do I connect the RLNK-P415 to my network for remote monitoring?
The unit features a LAN output port for IP connectivity. It also supports Wi-Fi connectivity when used with a 3rd party dongle.
What mounting options are available for the RLNK-P415?
This PDU includes a mounting bracket specifically for on-wall installation, facilitating its use in slim profiles behind displays.
What additional sensors can I add to this PDU?
The RLNK-P415 is compatible with the Premium+ Series PDU Dry Contact Sensor and the Premium+ PDU Temperature and Humidity Sensor.
Can I manage multiple PDUs from a single interface?
Yes, using RackLink™ Cloud, AV professionals can use a centralized dashboard to manage multiple Premium+ PDUs along with other manufacturers' devices.
