Da-Lite Myriad Reveal, 120" x 192" with Da-Tex - DL100195EL
Large venue rear projection screen, 120" x 192" with Da-Tex surface and SightLine adjustable cable drop
The DL100195EL is a Myriad Reveal series electric screen designed for large venue applications such as lecture halls, ballrooms, and conference centers. This specific configuration features a 120" x 192" wide (16:10) screen surface with Da-Tex material, optimized for rear projection. It utilizes the SightLine cable drop feature, which allows for a fully adjustable vertical placement up to 16' (5 m) between the ceiling and the top of the screen. This eliminates the standard black drop and provides usable space above the viewing area for speaker or camera placement. For installation, the unit provides built-in case leveling of ±.5" (12.7 mm) vertically and centering adjustability of ±6" (152.4 mm) horizontally. This model is TAA compliant and includes low voltage control. It is suitable for both ceiling and wall mounting applications.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Screen Diagonal | 226 in (574 cm) |
| Screen Height | 120 in (304.8 cm) |
| Screen Width | 192 in (487.7 cm) |
| Shipping Dimensions | 230.79" x 13" x 20.25" (586.2 x 33 x 51.4 cm) |
| Shipping Weight | 552 lbs (250.4 kg) |
| Size | 120" x 192" or 226" diagonal |
| Application | CeilingWall |
| Built-In Control | Low Voltage Control |
All other specifications 11
| Drop Type | SightLine Cable Drop |
| Federal Ops Country of Origin | US |
| Motor | 220V (50Hz) for Export |
| Projection Type | Rear Projection |
| Screen Format | Wide (16:10) |
| Screen Surface Features | Standard Resolution |
| Screen Type | Electric |
| Special Features | Large Venue |
| Surface | Da-Tex |
| TAA Compliant | Yes |
| Certifications | TAA |
Resources
You'll need these with it
Da-Lite Screen Controller with RF (BLE) Remote - DL16522
DL16522$660.00
Da-Lite Screen Controller with Infrared Remote - DL16524
DL16524$605.60
Da-Lite Screen Controller with RF (BLE) Remote and PoE Injector - DL16523
DL16523$707.20
Da-Lite Screen Controller with Infrared Remote and PoE Injector - DL16525
DL16525$652.00
Da-Lite Screen Controller with PoE Injector - DL16521
DL16521$551.20
Da-Lite Locking Switch Cover Plate
98837$102.40
Da-Lite Screen Controller - DL15316
DL15316$504.00
Questions about this part
Will the DL100195EL fit my rear projection setup?
This model is configured for rear projection using a Da-Tex surface with a 16:10 wide screen format.
What is the maximum cable drop for this SightLine model?
The SightLine feature allows for a variable cable drop distance of up to 16' (5 m) between the ceiling and the top of the screen.
How is the screen mounted in a ceiling or wall?
The Myriad Reveal series features versatile brackets for both ceiling and wall mounting, including built-in vertical and horizontal adjustment capabilities.
Is this screen TAA compliant?
Yes, this product is TAA compliant.
What control options are compatible with this screen?
This unit features low voltage control and is compatible with various Da-Lite screen controllers, including RF, Infrared, or PoE options like the DL16523.
