Da-Lite Designer Contour Electrol, 60" x 60" with High Contrast Matte White - 92660EL
60" x 60" square electric projection screen featuring High Contrast Matte White surface and low voltage control
The Da-Lite Designer Contour Electrol 92660EL is a square, electric projection screen measuring 60" x 60" with an 85 in (215.9 cm) diagonal. This model is configured with a High Contrast Matte White non-tensioned surface designed for front projection. The unit features a compact housing profile, measuring 4 5/8” high by 4 3/32” deep, allowing for a low-profile installation on either a ceiling or a wall. This specific SKU is equipped with a 220V (50Hz) motor for export markets and includes built-in low voltage control. The screen utilizes a standard black backing to help retain projected brightness. This TAA compliant solution is manufactured in the US and provides a professional, seamless appearance in any installation environment.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Screen Diagonal | 85 in (215.9 cm) |
| Screen Height | 60 in (152.4 cm) |
| Shipping Weight | 34 lbs (15.4 kg) |
| Size | 60" x 60" |
| Application | CeilingWall |
| Built-In Control | Low Voltage Control |
| Federal Ops Country of Origin | US |
| Motor | 220V (50Hz) for Export |
All other specifications 6
| Projection Type | Front Projection |
| Screen Format | Square |
| Screen Surface Features | Standard Resolution |
| Screen Type | Electric |
| Surface | High Contrast Matte White (non-tensioned) |
| Certifications | TAA |
Resources
You'll need these with it
Da-Lite Screen Controller with RF (BLE) Remote - DL16522
DL16522$660.00
Da-Lite Screen Controller with Infrared Remote - DL16524
DL16524$605.60
Da-Lite Screen Controller with RF (BLE) Remote and PoE Injector - DL16523
DL16523$707.20
Da-Lite Screen Controller with Infrared Remote and PoE Injector - DL16525
DL16525$652.00
Da-Lite Screen Controller with PoE Injector - DL16521
DL16521$551.20
Da-Lite Low Voltage Wall Switch
40975$92.80
Da-Lite Locking Switch Cover Plate
98837$102.40
Da-Lite Screen Controller - DL15316
DL15316$504.00
Questions about this part
What is the screen size for the Da-Lite 92660EL?
This is a square 60" x 60" screen with an 85 in (215.9 cm) diagonal.
What mounting options are available for this screen?
The Designer Contour Electrol can be installed in either ceiling or wall applications.
Is the Da-Lite 92660EL TAA compliant?
Yes, this product is TAA compliant and is manufactured in the US.
Can I add remote control to this screen?
Yes, you can add a Da-Lite Screen Controller with an RF (BLE) remote (SKU DL16522) or an Infrared remote (SKU DL16524).
What wall control options are compatible with the 92660EL?
You can install a Da-Lite Low Voltage Wall Switch (SKU 40975) or a locking switch cover plate (SKU 98837) for security.
