Da-Lite Cosmopolitan Series, 144" x 144" with Matte White - 40823L
144" x 144" electric square projection screen with matte white surface for large venue front projection applications
The Da-Lite 40823L is a large venue electric projection screen from the Cosmopolitan Series, featuring a 144" x 144" square format. Designed for both ceiling and wall mounting, this screen utilizes a matte white, non-tensioned surface optimized for front projection. This specific model includes built-in low voltage control and a standard 120V (60Hz) motor to facilitate simplified electrical integration. Because this unit has a 204 in (518.2 cm) diagonal and a 144 in (365.8 cm) width and height, it utilizes a two-piece aluminum case equipped with mounting brackets designed for high-diagonal installations. The housing features a standard white powder-coated finish and a black backing to help retain projected brightness. This TAA compliant, US-made screen is an ideal solution for large-scale environments requiring a seamless, high-quality square projection surface.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Screen Diagonal | 204 in (518.2 cm) |
| Screen Height | 144 in (365.8 cm) |
| Screen Width | 144 in (365.8 cm) |
| Shipping Dimensions | 162" x 13" x 20" (411.5 x 33 x 50.8 cm) |
| Shipping Weight | 366 lbs (166 kg) |
| Size | 144" x 144" |
| Application | CeilingWall |
| Built-In Control | Low Voltage Control |
All other specifications 11
| Federal Ops Country of Origin | US |
| Motor | Standard 120V (60Hz) |
| Projection Type | Front Projection |
| Screen Format | Square |
| Screen Surface Features | Standard Resolution |
| Screen Type | Electric |
| Special Features | Large Venue |
| Surface | Matte White (non-tensioned) |
| TAA Compliant | Yes |
| UPC | 717068017139 |
| Certifications | TAA |
Resources
You'll need these with it
Da-Lite Ceiling Trim Kit - 96384
96384$332.80
Da-Lite Screen Controller - DL15316
DL15316$504.00
Da-Lite Screen Controller with PoE Injector - DL16521
DL16521$551.20
Da-Lite Screen Controller with RF (BLE) Remote - DL16522
DL16522$660.00
Da-Lite Screen Controller with Infrared Remote and PoE Injector - DL16525
DL16525$652.00
Da-Lite Screen Controller with RF (BLE) Remote and PoE Injector - DL16523
DL16523$707.20
Da-Lite Screen Controller with Infrared Remote - DL16524
DL16524$605.60
Smart Low Voltage Wall Switch
DL16622$92.80
Da-Lite Locking Switch Cover Plate
98837$102.40
Questions about this part
Will the Da-Lite 40823L fit my square projection needs?
Yes, this model features a 144" x 144" square screen format, providing a 204 in (518.2 cm) diagonal for large venue applications.
What is required for the installation of the 40823L?
This unit uses a two-piece aluminum case with mounting brackets for wall or ceiling installation. It includes built-in low voltage control for electrical integration.
Can I control the 40823L with a remote or wall switch?
The screen is compatible with various Da-Lite controllers, including the DL16522 RF (BLE) Remote or the DL16524 Infrared Remote.
What is the difference between the 40823L and the Myriad Reveal series?
The Cosmopolitan Series is currently being phased out in favor of the Myriad Reveal, which offers updated aesthetics and features like SightLine Cable Drop.
Is this screen TAA compliant?
Yes, the Da-Lite 40823L is TAA compliant and is manufactured in the US.
