Da-Lite Contour Electrol, 108" x 108" with Matte White - 88341LS
108" x 108" square electric projection screen, matte white non-tensioned surface, with standard low voltage control
The Da-Lite 88341LS is a square format electric projection screen measuring 108" x 108" with a 153 in (388.6 cm) diagonal. Designed for front projection applications, this non-tensioned screen features a matte white surface to provide standard resolution clarity. It is built with a standard black backing to help retain projected brightness. This model utilizes a standard 120V (60Hz) motor and a standard silent drive system to ensure whisper-quiet operation. Installation is versatile, as this unit is designed for both ceiling and wall mounting. It comes equipped with standard low voltage control (LVC) and a dry contact interface, which includes a projector trigger (5-12V). This TAA compliant screen is finished with a white powder-coated aluminum housing, though black finishes are available upon request. Note that this specific SKU is a non-tensioned model and does not include the Tensioning Cable System.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Screen Diagonal | 153 in (388.6 cm) |
| Screen Height | 108 in (274.3 cm) |
| Shipping Dimensions | 126" x 13" x 10" (320 x 33 x 25.4 cm) |
| Shipping Weight | 79 lbs (35.8 kg) |
| Size | 108" x 108" |
| Application | CeilingWall |
| Built-In Control | Standard Low Voltage Control |
| Federal Ops Country of Origin | US |
All other specifications 9
| Motor | Standard 120V (60Hz) |
| Projection Type | Front Projection |
| Screen Format | Square |
| Screen Surface Features | Standard Resolution |
| Screen Type | Electric |
| Surface | Matte White (non-tensioned) |
| TAA Compliant | Yes |
| UPC | 717068228443 |
| Certifications | TAA |
Resources
You'll need these with it
Da-Lite Screen Controller with Infrared Remote - DL16524
DL16524$605.60
Da-Lite Screen Controller with PoE Injector - DL16521
DL16521$551.20
Da-Lite Screen Controller with RF (BLE) Remote - DL16522
DL16522$660.00
Da-Lite Screen Controller with RF (BLE) Remote and PoE Injector - DL16523
DL16523$707.20
Da-Lite Screen Controller with Infrared Remote and PoE Injector - DL16525
DL16525$652.00
Da-Lite Screen Controller - DL15316
DL15316$504.00
Smart Low Voltage Wall Switch
DL16622$92.80
Da-Lite Locking Switch Cover Plate
98837$102.40
Questions about this part
What is the screen size and format for the Da-Lite 88341LS?
This is a square format screen measuring 108" x 108" with a 153 in (388.6 cm) diagonal.
Can I add remote control to this screen?
Yes, you can integrate compatible controllers such as the Da-Lite Screen Controller with Infrared Remote (DL16524) or the Da-Lite Screen Controller with RF (BLE) Remote (DL16522).
What type of mounting is required for the 88341LS?
This electric screen is designed for both ceiling and wall applications.
Is this screen suitable for government contracts?
Yes, the 88341LS is TAA compliant and was manufactured in the US.
How does this model differ from tensioned versions?
This SKU is a non-tensioned model. If you require a Tensioned Contour Electrol system, you must select a different model.
