Da-Lite Advantage Series, 96" x 96" with Matte White - 84258ELS
Square 96" x 96" ceiling recessed electric screen with Matte White surface and 220V motor for export
The Da-Lite 84258ELS is a square-format ceiling recessed electric screen designed for professional large venue environments. Featuring a 96" x 96" dimensions and a 136 in (345.4 cm) screen diagonal, this model utilizes a Matte White non-tensioned surface optimized for front projection. The unit is equipped with a 220V (50Hz) motor intended for export markets and includes a standard black drop to maintain high projected brightness on the front surface. This Advantage Series model is TAA compliant and features a UL plenum rated case with a white powder-coated finish. The design allows for a two-stage installation: the screen case can be mounted during the rough-in construction stage, while the surface assembly is installed during the finishing stage. The integrated slot closure door and standard low voltage control provide a clean, professional aesthetic once recessed into the ceiling.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Screen Diagonal | 136 in (345.4 cm) |
| Screen Height | 96 in (243.8 cm) |
| Shipping Dimensions | 110" x 13" x 10" (279.4 x 33 x 25.4 cm) |
| Shipping Weight | 92 lbs (41.7 kg) |
| Size | 96" x 96" |
| Application | Ceiling Recessed |
| Built-In Control | Standard Low Voltage Control |
| Closure Door | Slot |
All other specifications 13
| Drop Type | Standard Black Drop |
| Federal Ops Country of Origin | US |
| Motor | 220V (50Hz) for Export |
| Product Selection | Complete Screen |
| Projection Type | Front Projection |
| Screen Format | Square |
| Screen Surface Features | Standard Resolution |
| Screen Type | Electric |
| Special Features | Large Venue |
| Surface | Matte White (non-tensioned) |
| TAA Compliant | Yes |
| UPC | 717068164826 |
| Certifications | TAA |
Resources
You'll need these with it
Da-Lite Screen Controller with Infrared Remote - DL16524
DL16524$605.60
Da-Lite Screen Controller with PoE Injector - DL16521
DL16521$551.20
Da-Lite Screen Controller with RF (BLE) Remote - DL16522
DL16522$660.00
Da-Lite Screen Controller with RF (BLE) Remote and PoE Injector - DL16523
DL16523$707.20
Da-Lite Screen Controller with Infrared Remote and PoE Injector - DL16525
DL16525$652.00
Da-Lite Screen Controller - DL15316
DL15316$504.00
Smart Low Voltage Wall Switch
DL16622$92.80
Da-Lite Locking Switch Cover Plate
98837$102.40
Questions about this part
Will this screen work with my existing control system?
This SKU includes standard low voltage control. For additional flexibility, you can add a Da-Lite Screen Controller such as the DL16521 with a PoE Injector or the DL16522 RF (BLE) Remote version.
Is this screen suitable for plenum environments?
Yes, the case for the 84258ELS is UL plenum rated, making it suitable for installation in plenum ceiling spaces.
What is the vertical placement range for the screen surface?
The Advantage Series supports variable vertical placement with cables that accommodate a standard drop distance of up to 70" between the ceiling and the top of the screen.
What mounting requirements are needed for a recessed install?
The two-stage installation allows for the screen housing to be installed during rough-in, while the surface is added during finishing. Sliding installation brackets provide flexibility for mounting to the structure above the drop ceiling.
Does this screen require any additional components for operation?
While it includes standard low voltage control, you may require a Da-Lite Smart Low Voltage Wall Switch (DL16622) or various controller options for infrared or RF operation.
