14 Inch No Cover Enclosure
14-inch steel enclosure with universal bay-style mounting for versatile module installation
The On-Q EN1480 is a 14-inch steel enclosure designed for professional structured wiring installations. This enclosure features universal On-Q bay-style mounting holes, making it compatible with all bay-style modules. For easier technician access, the unit includes larger top openings to facilitate wire pulling, along with additional knockouts, side tabs, and extra side lances for increased installation flexibility. This steel enclosure supports both flush and surface mounting, and includes drywall depth indicators to assist with precise placement. The design is part of a scalable series that ranges from 12" to 42" to accommodate different project requirements. It is made in the USA.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
| Color | White |
| Material | Steel |
Resources
You'll need these with it
2 Inch Rubber Grommet Pack for Plastic Enclosure - 5 Pack
AC1034$2.99
Shelf Mounting Bracket
AC1060$16.99
5 Inch Mounting Plate Combo Kit
AC1050EMK$29.99
Half Width Enclosure Power Strip Module
AC1031$69.99
Cable Management Clips
AC103520$24.99
5 Inch Mounting Plate with 1.5 Inch Elevation
AC1050$24.99
Plastic Enclosure Cable Channels - 2 Pack
AC1052CC2$5.49
Forward Combo Pack - Small Device Mounting Clamps and Keyhole Post Clips
AC1051RCKH4$8.99
On-Q 6 Outlet Enclosure Surge Protector with One USB-A and One USB-C
AC1062$34.99
Universal Mounting Plate
AC1040F$32.99
Questions about this part
What modules are compatible with the EN1480?
The EN1480 is compatible with all On-Q bay-style modules through its universal mounting hole system.
Can this enclosure be mounted flush against a wall?
Yes, this enclosure supports both flush and surface installation, and includes mounting tabs to ensure the correct flush-mount position.
Does this enclosure work with other On-Q accessories?
Yes, it is compatible with accessories such as the AC1031 half-width power strip module, AC1040F universal mounting plates, and AC1062 surge protectors.
How can I identify cables inside the enclosure?
The enclosure includes a self-adhesive cable identification table to assist with organized wire management.
Which documents provide installation details for this series?
The Core Enclosure Line 14", 20", 28", and 42" Installation Instructions PDF provides detailed guidance for this product line.
