Select Series PDU with RackLink™, 10 Outlet
Vertical intelligent PDU with 10 outlets, 4 controlled via IP, and RackLink™ Cloud integration
The RLNK-1015V is a Select Series PDU with RackLink™ designed to provide intelligent power distribution and remote monitoring in space-constrained rack environments. This 15 Amp vertical PDU features 10 total IEC outlets, with 4 specific outlets that support individual IP control. These controlled outlets, identified by a white square on the face, allow installers to manage the start-up or shut-down of equipment via remote sequencing with user-selectable delays. This unit features basic surge protection to shield connected devices from power anomalies. By utilizing the RackLink™ Cloud, AV professionals can monitor and manage deployed PDUs globally from a single, customizable dashboard. The system is compatible with the RackLink Discovery app on iPhone and Android for rapid commissioning and provides an interface for 3rd party AV control systems. This ETL Listed unit is a Control Concepts Supported Product and can be integrated into Crestron Certified Modules and Q-SYS Certified Plug-ins.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Amps | 15 Amp |
| Cord Length | 9 ft (2.7 m) |
| Depth | 1.63 in (4.1 cm) |
| Height | 35.61 in (90.5 cm) |
| Shipping Weight | 4 lbs (1.8 kg) |
| Width | 1.89 in (4.8 cm) |
| Available Internationally | No |
| Cable Type | IEC |
All other specifications 10
| Finish | Black Anodized |
| Mounting Style | Vertical |
| Number of Circuits | 1 |
| Outlet Control Type | 4 |
| Outlet Count | 10 |
| Plug Type | 5-15P |
| Surge Protection Type | Basic |
| TAA Compliant | No |
| UPC | 656747275333 |
| Certifications | ETL Listed |
Resources
Questions about this part
Can I control specific outlets on the RLNK-1015V remotely?
Yes, 4 of the 10 IEC outlets feature individual IP control, which are marked with a white square to distinguish them from the standard outlets.
What do I need to use the RackLink™ Cloud features?
You can use the free RackLink Cloud to manage your Select Series PDUs from a single dashboard; additionally, the RackLink Discovery app is available for iPhone and Android devices for commissioning.
How does the remote sequencing work on this PDU?
The RLNK-1015V allows for remote sequencing with user-selectable delays, which helps manage the optimal power-up or power-down progression of your connected equipment.
Is the RLNK-1015V compatible with third-party control systems?
Yes, it interfaces with third-party AV control systems and cloud platforms for scheduling, custom reporting, and control functionality.
Does this PDU provide surge protection?
The RLNK-1015V includes basic surge protection designed to protect your devices from harmful power anomalies.
