Proximity® Component Storage Panel Under Table
Under-table component storage panel with 20 lbs capacity, featuring a 90° pivot for easier servicing
The Chief CSPH is designed to organize components and cables beneath conference room tables or desks, effectively eliminating clutter in professional environments. This storage panel provides a 14” x 25.5” (357 sq. in.) active mounting area, making it a reliable choice for large-scale rollouts where consistent component placement is required. Installers can populate the panel at a staging area before mounting, which streamlines on-site deployment. Once the unit is installed under the table, it can pivot 90° to a vertical position, allowing technicians to service components without fighting gravity. For installations with limited clearance, the panel features 1/3 and 2/3 breakaway options. The CSPH is TAA compliant and carries a 20 lbs (9.07 kg) weight capacity.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Depth | 1.15 in (2.9 cm) |
| Height | 27.31 in (69.4 cm) |
| Overall Dimensions | 27.31 x 14.40 x 1.15” (693 x 366 x 29 mm) |
| Shipping Weight | 10.2 lbs (4.6 kg) |
| Weight Capacity | 20 lbs (9.07 kg) |
| Width | 14.4 in (36.6 cm) |
| Accessory Type | Component Storage |
| Application | Under Table |
All other specifications 6
| Color | Black |
| Mounting Method | Under Table |
| Solution Type | Storage Panel |
| TAA Compliant | Yes |
| UPC | 841872170930 |
| Certifications | TAA |
Resources
You'll need these with it
Questions about this part
How do I access components once the CSPH is mounted?
The panel can be pivoted 90° to a vertical position, which allows for easier access to cables and hardware.
What is required to install the CSPH under a table?
You will need to purchase the Proximity® Component Storage Panel Under Table Hinge Bracket (SKU: CSPHK) to facilitate mounting.
Can the panel be customized for smaller spaces?
Yes, the panel includes 1/3 and 2/3 breakaway sections so you can reduce the size if space is limited.
Is this product TAA compliant?
Yes, the CSPH is TAA compliant, making it suitable for various commercial and government requirements.
What are the mounting dimensions for the CSPH?
The unit has overall dimensions of 27.31 x 14.40 x 1.15” (693 x 366 x 29 mm) and a mounting area of 14” x 25.5”.
