Outdoor Flat Panel Single Ceiling and Pedestal Mount, Extra-Large

Extra-large outdoor mount for 65" to 84" displays, 250 lbs capacity, with tilt adjustment and weatherproof construction

The OXCM1U is an extra-large outdoor single display mount designed for ceiling or floor-cart applications in demanding environments. Engineered to withstand high winds, humidity, ocean air, and direct sun exposure, this mount is UL 2442 Part 2 listed for outdoor use. It features a corrosion-resistant paint finish, UV-rated plastics, and stainless-steel hardware to ensure long-term durability. The system is delivered in three separate pieces—the mount, column, and plate—to allow for a safer, more manageable four-step installation process that reduces the lifting load for installers. This mount accommodates 65" to 84" displays with a VESA mounting pattern ranging from 200 x 100mm to a maximum of 800 x 400mm. It offers a tilt range of +7.6° to -20°, utilizing set locking points to eliminate guesswork when adjusting multiple displays in the field. For installations subject to high wind loads, the unit is wind-compatible up to a 2000 ft-lbs maximum moment force. This model is TAA compliant and provides a heavy-duty solution with a 250 lbs weight capacity for landscape orientation displays.
