Outdoor Flat Panel 2x1 Ceiling and Pedestal Mount
Weatherproof dual-display mount for ceiling or pedestal installation, supporting up to 250 lbs with +7.6° to -20° tilt
The OLCM2X1U is a specialized outdoor mount designed for mounting two displays in a landscape orientation from either a ceiling or a floor-based pedestal. Engineered to withstand harsh environmental conditions, including rain, humidity, ocean air, and high winds, this system utilizes UV-rated plastics, stainless-steel hardware, and corrosion-resistant paint to ensure long-term durability. The weatherproof design meets UL 2442 Part 2 standards for outdoor use. To facilitate easier installation, the system is shipped in three distinct pieces—the mount, the column, and the plate—allowing for a safer, four-step lifting process. For precise alignment of dual displays, the mount offers a tilt range of +7.6° to -20° with integrated set locking points. This universal interface supports VESA mounting patterns from 200 x 100mm up to 800 x 400mm, making it compatible with a variety of outdoor-rated digital signage and displays.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Shipping Dimensions | 73.25" x 25" x 9.5" (186.1 x 63.5 x 24.1 cm) |
| Shipping Weight | 144.59 lbs (65.6 kg) |
| Weight Capacity | 250 lbs (113.4 kg) |
| Adjustability | Tilt |
| Application | CeilingFloor-Cart |
| Color | Black |
| Number of Displays | 2 |
| Orientation | Landscape |
All other specifications 6
| Special Features | Multi-DisplayOutdoor Use |
| TAA Compliant | Yes |
| Tilt | +7.6° to -20° |
| UPC | 841872171968 |
| VESA Mounting Pattern | 200 x 100mm - 800 x 400mm |
| Certifications | TAAUL Listed |
Resources
You'll need these with it
Verified fitment
Questions about this part
What is the tilt range for the OLCM2X1U mount?
The mount provides a tilt adjustment range of +7.6° to -20°, featuring set locking points to assist with the alignment of multiple displays.
Will this mount fit my specific display?
The universal interface is compatible with displays featuring VESA patterns up to 800 x 400mm, including models like the Samsung UN55CU8000FXZA and AKAI PDP5016H.
What other mounting options are available for this series?
The OLCM2X1U can be installed as a ceiling mount or a floor-cart/pedestal mount. You can also purchase the ODA330B Outdoor Concrete Ceiling and Pedestal Plate for specific mounting requirements.
Is this mount rated for high-wind environments?
Yes, the system is wind-compatible to a maximum moment force of 2000 ft-lbs. This value is used in engineering calculations to ensure configurations meet local safety requirements.
Does this mount require additional hardware for installation?
The system is delivered in three pieces (mount, column, and plate) to manage the 144.59 lbs (65.6 kg) shipping weight during a four-step installation process.
