Multi-Mount Rackmount Power, 16 Outlet, 15A & 3-Step Sequencing
1RU rackmount power with 16 outlets, including 10 always-on and 6 sequenced outlets with 3-step sequencing.
The PDS-1615R provides versatile power distribution with integrated sequencing functions to help manage system startup and save rack space. This 1RU unit features 16 total outlets, organized so that 10 outlets remain always on while 6 outlets are managed via a 3-step sequencing process. For improved electromagnetic compatibility, the unit includes a 9 ft (2.7 m) SignalSAFE™ power cord designed to minimize AC magnetic fields. To protect sensitive electronics, the PDS-1615R utilizes 2-stage surge protection that includes a notification feature. The 4.53 in (11.5 cm) shallow depth makes it suitable for space-constrained environments. This multi-mount device can be installed either horizontally or vertically using the reversible, adjustable mounting ears. Additionally, the outlet orientations are varied to accommodate a wide variety of plug styles.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Amps | 15 Amp |
| Cord Length | 9 ft (2.7 m) |
| Depth | 4.53 in (11.5 cm) |
| Height | 1.75 in (4.4 cm) |
| Rack Units | 1 RU |
| Shipping Weight | 7 lbs (3.2 kg) |
| Volts AC | 120 VAC |
| Width | 19 in (48.3 cm) |
All other specifications 11
| Cable Type | Corded |
| Mounting Points | 2 |
| Multi-Mount | Yes |
| Number of Circuits | 1 |
| Outlet Count | 16 |
| Plug Type | 5-15P |
| Sequencing | Yes |
| Surge Protection Type | 2-Stage |
| TAA Compliant | No |
| UPC | 656747129902 |
| Certifications | ETL Listed |
Resources
Questions about this part
How does the sequencing work on the PDS-1615R?
The unit features 3-step sequencing across 6 of its 16 outlets, while the remaining 10 outlets are always on.
What is the mounting requirement for this power distributor?
This is a 1RU multi-mount unit with reversible, adjustable mounting ears that support both horizontal and vertical installation.
Will this unit fit in my shallow rack?
Yes, the PDS-1615R has a shallow depth of 4.53 in (11.5 cm) to accommodate space-constrained installations.
What type of power cord is included?
The unit comes with a 9 ft (2.7 m) SignalSAFE™ power cord with a 5-15P plug type.
Which documentation is available for submittals?
Installers can refer to the Multi Mount Power A&E Specification Sheet or the PDS Series Instruction Sheet for technical details.
