Large Fixed Wall Mount - PST2000B
Low-profile fixed wall mount for large displays, featuring 200 lbs capacity and lateral shift for 16", 20", or 24" stud spacing
The Chief PST2000B is a low-profile, fixed wall mount designed for the installation of large flat panel TVs in retail, digital display, or commercial applications. This TAA compliant mount features an ultra-low-profile design with a 1.21" (3.1 cm) minimum depth. To complete the installation, a custom or universal PSB interface bracket must be purchased separately. This model provides an expanded wall plate opening to facilitate cable access and reduce the risk of interference with existing outlets. For installation on standard framing, the mount is compatible with 16", 20", and 24" (406mm and 610mm) center stud systems. It includes a Rapid Level System for hands-free leveling and a Q-Latch Mounting System to simplify installation while providing integrated security. Users can install displays in either landscape or portrait orientation, though rotating the screen without removing it requires a separate accessory like the PAC400 or MAC400.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Lateral Shift | 8 in (203.2 mm) |
| Minimum Depth | 1.21 in (3.1 cm) |
| Shipping Dimensions | 36.25" x 22" x 5.25" (920.8 x 558.8 x 133.4 mm) |
| Shipping Weight | 9 lbs (4.1 kg) |
| Wall Stud Compatibility | 16" and 24" (406mm and 610mm) |
| Weight Capacity | 200 lbs (90.7 kg) |
| Adjustability | Fixed |
| Application | Wall |
All other specifications 6
| Color | Black |
| Orientation | LandscapePortrait |
| Solution Type | Universal and Custom |
| TAA Compliant | Yes |
| UPC | 841872043395 |
| Certifications | TAA |
Resources
You'll need these with it
Verified fitment
Questions about this part
Will this mount fit my specific display?
The PST2000B is verified against 20 models from 3 manufacturers, including CISCO CS-BOARD55, SAMSUNG ME95C, and DYNASCAN DS751LT4. Check your manufacturer's VESA pattern for compatibility.
What else do I need to purchase for a full installation?
This SKU is a mount only and requires a custom or universal PSB interface bracket, which is sold separately.
Can I rotate the display from landscape to portrait?
The mount supports both orientations, but you can use a PAC400 or MAC400 accessory to rotate the screen without having to remove it from the wall.
How is the mounting hardware and leveling handled?
The mount utilizes a Rapid Level System for hands-free leveling during installation and the Q-Latch Mounting System for secure, simplified mounting.
What kind of wall mounting is required for this model?
This mount is designed for wall applications and is compatible with 16", 20", and 24" center stud systems.
