K3G320S, Kontour™ K3 3x2 Static Array Grommet Mount
Static 3x2 multi-monitor array mount for 4 or 6 displays, designed for grommet installation on desks or tables
The Chief K3G320S is a static 3x2 multi-monitor array mount designed to provide a stable, professional workstation solution for high-density display environments. This Kontour™ K3 series array is configured for 4 or 6 displays, making it a versatile choice for control rooms, security desks, and financial services workstations. This specific model is a grommet mount, designed for installation through a desk or tabletop with a hole size range of 0.38" to 3.5" (10mm - 89mm). The mounting solution supports desktop thicknesses between 0.5" and 5" (13mm - 127mm). To ensure a precise installation, users can utilize the post-installation leveling roll to achieve the desired alignment. This TAA-compliant array features tool-free integrated cable management to maintain a streamlined aesthetic and provides independent height, pan, and tilt adjustment for each individual monitor. The silver finish and modern design allow it to integrate into diverse professional settings, whether used in landscape or portrait orientations.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Shipping Dimensions | 41.5" x 18.5" x 5.5" (105.4 x 47 x 14 cm) |
| Shipping Weight | 36 lbs (16.3 kg) |
| Weight Capacity | 15 lbs (6.8 kg) |
| Adjustability | Tilt, Height Adjustable |
| Application | Desk-TabletopGrommet Mount |
| Array Configuration | 3x2 |
| Color | Silver |
| Desktop Thickness Range | 0.5" - 5" (13mm - 127mm) |
All other specifications 10
| Grommet Hole Size Range | 0.38" - 3.5" (10mm - 89mm) |
| Mounting Method | Grommet Mount |
| Number of Displays | 4 or 6 |
| Orientation | LandscapePortrait |
| Post-Installation Leveling Roll | Yes |
| Solution Type | Universal |
| Special Features | Multi-Display |
| TAA Compliant | Yes |
| UPC | 841872161693 |
| Certifications | TAA |
Resources
You'll need these with it
FSB1U, Small Flat Panel Universal Interface Bracket
FSB1U$56.80
Custom Interface Bracket for Cisco EX90 and K2-series Mounts
FSB4090B$312.80
Small Flat Panel Interface Brackets -
FSB4243B$61.60
Small Flat Panel Interface Brackets - FSB4245B
FSB4245B$61.60
K3 Series Desk Clamp Accessory, Silver
KRA500S$84.80
Laptop & Tablet Tray, Silver
KRA300S$88.00
50x50mm VESA Interface Bracket
FSB4073$47.20
Quick-Connect Interface for Dell® Monitors KSA1250B-2
KSA1250B-2$36.80
Small Flat Panel Interface Buttons and Hardware for FSR and FTR
FSB75100B$10.40
Small Flat Panel Interface Brackets - FSB4243B
FSB4243B$61.60
Interface Bracket
FSB4442B$104.00
Small Flat Panel Interface Brackets - FSB4394B
FSB4394BDiscontinued
Verified fitment
Questions about this part
Will the K3G320S work with my specific monitors?
This mount is verified against 3,851 display models from 164 manufacturers, including Samsung 170N, LG 15LC1, Philips 10BDL3051T, and Toshiba 14DL74.
What mounting hardware is required for installation?
This is a grommet mount designed for installation through a desk or tabletop; ensure your workstation has a hole size between 0.38" and 3.5" (10mm - 89mm).
Can I use this mount with a desk clamp instead?
Yes, while this SKU is a grommet mount, the K3 series is compatible with the KRA500S K3 Series Desk Clamp Accessory.
How do I adjust the monitors once they are mounted?
The K3G320S provides independent height, pan, and tilt adjustment for each display, and includes a post-installation leveling roll for fine-tuning.
What interface brackets are needed for my displays?
Depending on your monitor, you may need compatible interface brackets such as the FSB4041 for 200 x 200mm VESA or the FSB1U Small Flat Panel Universal Interface Bracket.
