Fusion® Above/Below IntelliSHOT Camera Mount for Extra-Large Displays
Camera and component shelf for Vaddio IntelliSHOT Above/Below systems, supporting extra-large displays up to 63" in height
The Chief FCA810E is a specialized component and camera shelf designed for the Vaddio IntelliSHOT Above/Below application. This accessory allows installers to secure video conferencing equipment or other AV components directly to a display, ensuring a clean and integrated appearance in professional conferencing environments. This specific SKU is engineered for extra-large displays and is compatible with all Chief Fusion® Series mounts. When installed, it supports a equipment height range of 37" to 63" (94 - 160cm). This shelf has a maximum weight capacity of 10 lbs (4.5 kg), making it suitable for the Vaddio IntelliSHOT series and similar video conferencing hardware. It is a TAA compliant solution for projects requiring specific procurement standards. This black-finish shelf provides a stable platform for hardware in large-format installations where mounting cameras above or below the screen is required.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
| Equipment Height Range | 37" - 63" (94 - 160cm) |
| Shipping Dimensions | 26" x 9.5" x 4.5"(660.4 x 241.3 x 114.3 mm) |
| Shipping Weight | 10 lbs (4.5 kg) |
| Typical Screen Size | Extra Large |
| Weight Capacity | 10 lbs (4.5 kg) |
| Width | N/A |
| Accessory Type | Camera ShelvesComponent Shelves |
| Application | Vaddio IntelliSHOT Above/Below |
| Color | Black |
| TAA Compliant | Yes |
| UPC | 841872176031 |
| Certifications | TAA |
Resources
You'll need these with it
Verified fitment
Questions about this part
Will the FCA810E fit my Vaddio IntelliSHOT camera?
Yes, it is designed for Vaddio IntelliSHOT Above/Below systems, including the IntelliSHOT-M and EasyIP 30 models.
What is the maximum weight capacity for this shelf?
The FCA810E supports a maximum weight capacity of 10 lbs (4.5 kg).
What mounting series is this shelf compatible with?
This accessory is compatible with all Chief Fusion® Series mounts.
Is this product TAA compliant?
Yes, the FCA810E is TAA compliant.
What is the height range for equipment on this shelf?
The shelf accommodates equipment with a height range of 37" to 63" (94 - 160cm).
