Flush Mount Dome and Bracket for Sony EVI-D70
Flush mount dome and bracket for Sony EVI-D70 and EVI-D100 PTZ cameras, featuring a 7.3-inch clear enclosure
The Vaddio 998-9000-070 is a ceiling application flush mount solution designed to house Sony PTZ cameras within a clean, recessed profile. This kit includes a 7.3-inch (18.54 cm) clear dome enclosure and the internal brackets required to support the Sony EVI-D70 or EVI-D100. The assembly features a white twist-and-lock trim ring to secure the clear dome in place. This unit is built with a plenum-rated metal back box, and a tile support brace is recommended for ceiling installations. This TAA compliant mounting solution allows for a low-profile aesthetic by integrating the camera into the ceiling architecture rather than mounting it externally. Note that the camera itself is not included with this mount.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Depth | 9.2 in (23.4 cm) |
| Height | 10.25 in (26 cm) |
| Product Weight | 7 lbs (3.2 kg) |
| Shipping Dimensions | 14" x 13" x 13" (355.6 x 330.2 x 330.2 mm) |
| Width | 9.2 in (23.4 cm) |
| Application | Ceiling |
| Color | White |
| Compatible With | Sony |
All other specifications 6
| OneLINK Compatibility | No |
| Quick-Connect Compatibility | No |
| TAA Compliant | Yes |
| UPC | 840077500665 |
| Certifications | CEFCCTAA |
| Warranty | 3 years |
Resources
Verified fitment
Questions about this part
Which Sony cameras are compatible with the 998-9000-070?
This dome is specifically designed to support the Sony EVI-D70 and EVI-D100 PTZ camera models.
What is included in the 998-9000-070 kit?
The kit provides a 7.3-inch clear dome, a white twist-and-lock trim ring, and the internal brackets for the Sony EVI-D70 or EVI-D100.
Does this mount require additional hardware for ceiling installation?
The metal back box is plenum-rated, but a tile support brace is recommended for secure ceiling mounting.
Is this mounting solution TAA compliant?
Yes, the 998-9000-070 is TAA compliant and carries FCC and CE certifications.
Where can I find the installation manual for this dome?
You can access the DomeVIEW Flush Mount Tech Spec and the Flush Mount installation and connections manual in the resources tab.
