DocCAM 4K HDBT Document Camera
4K UHD ceiling-mount document camera with 30x optical zoom and HDBaseT, SDI, and HDMI output options
The Vaddio DocCAM 4K HDBT is a high-performance 4K UHD document camera designed for high-resolution overhead imaging in educational and corporate environments. This ceiling-mounted camera provides 2160p at 30fps resolution, utilizing an 8.57 Megapixel 1/2.5-type Exmor R CMOS sensor to deliver exceptional clarity. The unit features a 30x optical zoom and a horizontal field of view that ranges from 70.2° at the wide end down to 3.1° at the tele end. For versatile installation, it supports multiple signal types including 3G SDI, HDbT, HDMI, IP Streaming, and USB 3.0. Integration is streamlined through native OneLINK compatibility, allowing for power, video, and control over a single cable when used with Vaddio OneLINK HDMI or OneLINK Bridge extension systems. This setup can extend reaches up to 328 ft (100m) and supports remote management via a built-in web user interface. The DocCAM 4K HDBT is TAA compliant and features a low-power laser pointer to assist with centering on a tabletop or specimen.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Depth | 8 in (20.3 cm) |
| Height | 4.25 in (10.8 cm) |
| Operating Temperature | 32° to 104°F (0° to 40°C) |
| Overall Dimensions | 38.2" x 23.7" x 6.3" (970.3 x 602 x 160.1 mm) |
| Product Weight | 4.2 lbs (1.9 kg) |
| Shipping Weight | 13 lbs (5.9 kg) |
| Width | 8 in (20.3 cm) |
| 3rd Party Control | RS232Telnet |
All other specifications 35
| Browser-based User Interface for Remote Control | Built-in |
| Camera Type | Document |
| Color | White |
| Compatible With | Vaddio |
| Control Method | IR RemoteJoystickRS232TelnetTouch ScreenVaddio Device ControllerWeb UI |
| Estimated Room Size | Large RoomMedium RoomSmall Room |
| Extension Type | Camera |
| Field of View | 70.2° Wide End to 3.1° Tele End |
| Field of View Wide | Greater than 70 |
| Focus System | AutoManual |
| Gain | AutoManual |
| Image Sensor Type | 1/2.5-type Exmor R CMOS sensor |
| Input Ports | HDbT |
| Invertible | No |
| Manufacturer | Vaddio |
| Max Resolution | 2160p 30 |
| OneLINK Bridge adds | 328 ft (100m) Power Video Control Extension3G SDIAudio MixerHDMIUSB 3.0 |
| OneLINK Compatibility | Native |
| OneLINK HDMI adds | 328ft (100M) Power Video Control ExtensionHDMI |
| Output Ports | HDbTHDMIIP StreamingSDI |
| Pixels | 8.57 Megapixel |
| Power Type | Local PowerOneLINKPoE+ |
| Preset Positions | 1616 Custom Home Position |
| PTZ Motors | No Motors Manual |
| Quick-Connect Compatibility | No |
| Signal Type | 3G SDIHDbTHDMIIP StreamingUSB 3.0 |
| Solution Type | Camera Only |
| TAA Compliant | Yes |
| Tri-Sync Motion | No |
| UPC | 840077508715 |
| Video SN Ratio | Greater than 50 dB |
| White Balance | ATWAutoIndoorManualOne PushOutdoor |
| Zoom | 30x optical zoom |
| Certifications | CEFCCHDBaseTRoHSTAAUL |
| Warranty | 3 years |
Resources
You'll need these with it
Questions about this part
Will the DocCAM 4K HDBT fit my installation requirements?
This camera is designed for ceiling mounting in small, medium, or large rooms. It is ideal for higher education classrooms, medical operating theaters, and technical training sessions.
What cables and outputs are needed for the DocCAM 4K HDBT?
The camera provides 3G SDI, HDMI, HDbT, IP Streaming, and USB 3.0 outputs. It is natively compatible with Vaddio OneLINK HDMI and OneLINK Bridge extension systems.
How far can I run the video and power cable?
When using Vaddio OneLINK extension systems, you can extend power, video, and control up to 328 ft (100m).
Can I control the camera remotely?
Yes, you can manage the camera via a built-in web user interface, RS232, Telnet, or the Vaddio Device Controller.
What tools and accessories are needed for installation?
A Hard Ceiling Installation Kit (998-2225-152) is available for ceiling mounting. Refer to the installation guide for specific mounting requirements.
