Compact Premium+ PDU With RackLink™, 4 Outlet 20A & 2-Stage Surge
Compact Premium+ PDU with RackLink™, 4 NEMA 5-20R outlets, 20A capacity, and 2-stage surge protection
The RLNK-P420 is a Middle Atlantic Premium+ PDU designed to monitor digital signage installations and protect sensitive displays or dvLED tiles from power anomalies. This compact unit features 4 NEMA 5-20R outlets and a 20 Amp capacity, making it a specialized solution for environments where space is limited, such as behind displays. It utilizes 2-stage MOV surge protection to safeguard hardware against electrical spikes. For remote management, the unit offers RackLink™ Cloud compatibility, allowing AV professionals to manage PDUs and other manufacturer devices through a single centralized dashboard. Connectivity is maintained via IP, with options to connect via Wi-Fi using a 3rd party dongle. The RLNK-P420 supports advanced features like integrated scheduling, variable timed sequencing, and auto-healing to ensure maximum uptime for mission-critical digital signage. This unit is UL Listed and FCC compliant, meeting AVIXA Energy Management Standards for efficient system design.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
| AC Voltage Input | 80-140 V |
| Amps | 20 Amp |
| Shipping Weight | 6.5 lbs (3 kg) |
| Available Internationally | No |
| Outlet Count | 4 |
| Output Ports | LAN |
| Receptacle Type | NEMA 5-20R |
| Surge Protection Type | 2-Stage |
| TAA Compliant | No |
| UPC | 656747363351 |
| Certifications | FCCUL Listed |
Resources
Questions about this part
Will the RLNK-P420 fit in my display enclosure?
Yes, this unit features a slim form factor designed to be easily concealed behind displays or dvLED tile walls.
How do I connect to the RLNK-P420 for remote management?
The PDU provides IP connectivity and can connect via Wi-Fi if a 3rd party dongle is used.
What accessories are compatible with the RLNK-P420?
You can add the Premium+ Series PDU Dry Contact Sensor, the RackLink™ Cloud service, or the Premium+ PDU Temperature and Humidity Sensor.
What mounting options are available for this PDU?
The RLNK-P420 includes a mounting bracket specifically for on-wall installation.
Does the RLNK-P420 support remote firmware updates?
Yes, you can remotely update the firmware without having to shut down the PDU, which helps maintain system uptime.
