6ft (1.8m) USB-C® to USB-A 3.2 Gen 1 (5Gbps) Cable M/M - White
6ft USB-C to USB-A 3.2 Gen 1 cable for 5Gbps data transfer and 3A charging, white finish
The CG28836 is a 6ft (1.8m) USB-C to USB-A 3.2 Gen 1 (5Gbps) Male to Male cable designed for connecting USB-C enabled devices to standard USB-A ports. This white cable supports bidirectional signal transmission for simultaneous data transfer and power delivery. It is engineered to provide a 3A charging output, ensuring that laptops, smartphones, or tablets stay powered while moving photos, music, or files at speeds up to 5Gbps. The USB-C connector features a symmetrical, reversible design, allowing for easy insertion into ports without worrying about orientation. This cable utilizes a 30AWG wire gauge and a PVC jacket with a VW-1 rating. It operates within a temperature range of 32° to 122°F (0° to 50°C) and is rated for 30V. For longer distances, a 10ft version (CG28837) is available in the same series.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Amps | 3 Amp |
| Bend Radius | 1.89 in (48 mm) |
| Cable Diameter | 0.19 in (4.8 mm) |
| Cable Length | 6 ft (1.8 m) |
| Operating Humidity Max | 85% RH (Non-Condensing) |
| Operating Humidity Min | 15% RH (Non-Condensing) |
| Operating Temperature | 32° to 122°F (0° to 50°C) |
| Shipping Weight | 0.17 lbs (0.1 kg) |
All other specifications 20
| Signal Transmission | Bidirectional |
| Storage Humidity Max | 85% RH (Non-Condensing) |
| Storage Humidity Min | 15% RH (Non-Condensing) |
| Storage Temperature | -13° to 158°F (-25°C to 70°C) |
| Storage Temperature Max | 158 Fahrenheit (70 Celsius) |
| Storage Temperature Min | -13 Fahrenheit (-25 Celsius) |
| Wire Gauge | 30 |
| Cable Type | USB |
| Color | White |
| Connector 1 | (1) USB-C Male(1) USB-C Male |
| Connector 2 | (1) USB-A Male(1) USB-A Male |
| Jacket Rating | VW-1 |
| Product Type | Cable |
| TAA Compliant | No |
| Technology Specifications | USB 3.0 |
| UPC | 757120288367 |
| Certifications | NDAA 889Prop 65REACHRoHSTSCA |
| Data Transfer Rate | 5 GBPS |
| Jacket Material | PVC |
| Warranty | Lifetime |
Resources
You'll need these with it
6in Cable Tie Multipack - 100 Pack - Black
CG43037$14.99
0.5ft (0.15m) USB-C® Female to USB-A Male SuperSpeed USB 5Gbps Adapter Converter
CG54428$22.99
0.68in Self-Adhesive Cable Clamp Multipack - 50 Pack
CG43053$86.99
11in Hook-and-Loop Cable Management Wrap Multipack (12-Pack) - Black
CG29854$16.99
USB-C® 9-in-1 Dual Display Docking Station with HDMI®, Ethernet, USB, 3.5mm Audio and Power Delivery up to 60W - 4K 30Hz (TAA Compliant)
C2G54488$189.99
USB-C® Male to USB-A Female Adapter Converter - USB 3.2 Gen 1 (5Gbps)
C2G29515$17.99
10ft (3m) USB-C® to USB-A 3.2 Gen 1 (5Gbps) Cable M/M - White
CG28837$29.99
USB-C® 12-in-1 Triple Display Docking Station with HDMI®, DisplayPort™, Ethernet, USB (TAA Compliant)
C2G54535Discontinued
Questions about this part
What is the maximum data transfer speed of the CG28836?
This cable supports SuperSpeed USB 5Gbps data transfer rates via USB 3.2 Gen 1 technology.
How much power can this USB-C cable deliver?
The CG28836 supports a 3A charging output for power delivery to compatible devices.
Is there a longer version of this white USB-C cable available?
Yes, the CG28837 is a 10ft (3m) version of this same USB-C to USB-A 3.2 Gen 1 cable.
Does the CG28836 support bidirectional data transfer?
Yes, it supports bidirectional signal transmission, allowing for simultaneous data and power usage.
What is the bend radius for this cable?
The minimum bend radius for this 6ft cable is 1.89 in (48 mm).
