10ft (3m) USB-C® to USB-A 3.2 Gen 1 (5Gbps) Cable M/M - White
10ft USB-C to USB-A 3.2 Gen 1 cable, 5Gbps data transfer, 3A charging, white PVC jacket
The CG28837 is a 10ft (3.1 m) USB-C to USB-A 3.2 Gen 1 (5Gbps) Male to Male cable designed for high-speed connectivity between USB-C enabled devices and standard USB-A accessories. This white cable supports bidirectional signal transmission, allowing for simultaneous data transfer and power delivery. It is capable of 3A charging output, ensuring that laptops, tablets, or smartphones remain powered while transferring photos, music, or files at SuperSpeed rates of up to 5Gbps. The USB-C connector features a symmetrical, reversible design that allows for immediate connection without concern for orientation, reducing wear on the connector port. Built with a 0.19 in (4.8 mm) diameter PVC jacket and a 30AWG wire gauge, this cable is rated with a VW-1 jacket rating. It is engineered to operate in temperatures from 32° to 122°F (0° to 50°C) and is compliant with RoHS, REACH, and TAA requirements.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Amps | 3 Amp |
| Bend Radius | 1.89 in (48 mm) |
| Cable Diameter | 0.19 in (4.8 mm) |
| Cable Length | 10 ft (3.1 m) |
| Operating Humidity Max | 85% RH (Non-Condensing) |
| Operating Humidity Min | 15% RH (Non-Condensing) |
| Operating Temperature | 32° to 122°F (0° to 50°C) |
| Shipping Weight | 0.34 lbs (0.2 kg) |
All other specifications 20
| Signal Transmission | Bidirectional |
| Storage Humidity Max | 85% RH (Non-Condensing) |
| Storage Humidity Min | 15% RH (Non-Condensing) |
| Storage Temperature | -13° to 158°F (-25°C to 70°C) |
| Storage Temperature Max | 158 Fahrenheit (70 Celsius) |
| Storage Temperature Min | -13 Fahrenheit (-25 Celsius) |
| Wire Gauge | 30 |
| Cable Type | USB |
| Color | White |
| Connector 1 | (1) USB-C Male(1) USB-C Male |
| Connector 2 | (1) USB-A Male(1) USB-A Male |
| Jacket Rating | VW-1 |
| Product Type | Cable |
| TAA Compliant | No |
| Technology Specifications | USB 3.0 |
| UPC | 757120288374 |
| Certifications | NDAA 889Prop 65REACHRoHSTSCA |
| Data Transfer Rate | 5 GBPS |
| Jacket Material | PVC |
| Warranty | Lifetime |
Resources
You'll need these with it
6in Cable Tie Multipack - 100 Pack - Black
CG43037$14.99
0.5ft (0.15m) USB-C® Female to USB-A Male SuperSpeed USB 5Gbps Adapter Converter
CG54428$22.99
11in Hook-and-Loop Cable Management Wrap Multipack (12-Pack) - Black
CG29854$16.99
USB-C® 9-in-1 Dual Display Docking Station with HDMI®, Ethernet, USB, 3.5mm Audio and Power Delivery up to 60W - 4K 30Hz (TAA Compliant)
C2G54488$189.99
USB-C® Male to USB-A Female Adapter Converter - USB 3.2 Gen 1 (5Gbps)
C2G29515$17.99
0.68in Self-Adhesive Cable Clamp Multipack - 50 Pack
CG43053$86.99
6ft (1.8m) USB-C® to USB-A 3.2 Gen 1 (5Gbps) Cable M/M - White
CG28836$26.99
USB-C® 12-in-1 Triple Display Docking Station with HDMI®, DisplayPort™, Ethernet, USB (TAA Compliant)
C2G54535Discontinued
Questions about this part
Will this USB-C to USB-A cable work for charging my device?
Yes, the CG28837 supports a 3A charging output, making it suitable for charging smartphones, tablets, and laptops via the USB-A port.
What is the maximum data transfer speed for this cable?
This is a SuperSpeed USB 3.2 Gen 1 cable that supports bidirectional data transfer rates up to 5Gbps.
What is the difference between this and the CG28836?
The CG28837 is the 10ft (3.1 m) version of this cable, while the CG28836 is a 6ft (1.8 m) version.
Is this cable compatible with docking stations?
This cable can be used with compatible docking stations, such as the C2G54535 USB-C 12-in-1 Triple Display Docking Station.
What is the bend radius for this cable?
The cable has a minimum bend radius of 1.89 in (48 mm).
