20ft (6.1m) Cat5e Snagless Unshielded UTP Ethernet Network Patch Cable - Gray
20ft Cat5e UTP patch cable with snagless boots and 24 AWG copper conductors, gray finish
The C2G CG00389 is a 20ft (6.1m) Cat5e Snagless Unshielded UTP Ethernet Network Patch Cable in Gray, designed for high-bandwidth voice, data, and video distribution applications. This cable meets all Cat5e TIA/EIA standards, providing reliable performance for fast Ethernet networks. It features a 0.21 in (5.3 mm) cable diameter and utilizes 24 AWG stranded copper conductors to minimize Near-End Crosstalk (NEXT) levels. The construction includes individual pairs that are bonded together to maintain twist-spacing throughout the line up to the termination point, which reduces impedance and structural return loss (SRL). For installation ease, the molded snagless PVC boots protect the RJ-45 clips from damage during plugging and unplugging and provide added strain relief. This unshielded (UTP) cable utilizes a T568B wiring scheme and is rated for a bandwidth of 350 mHz. The jacket is made of PVC and is suitable for standard, non-rated environments. This product is NDAA 889 compliant and carries CE, REACH, RoHS, and TSCA certifications.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Bandwidth | 350 mHz |
| Cable Diameter | 0.21 in (5.3 mm) |
| Cable Length | 20 ft (6.1 m) |
| Shield Type | UTP |
| Shipping Weight | 0.47 lbs (0.2 kg) |
| Wire Gauge | 24 |
| Wiring Scheme | T568B |
| Cable Shielding | Unshielded (UTP) |
All other specifications 15
| Cable Type | Cat5e |
| Category Performance Application | Cat5e |
| Color | Gray |
| Conductor Material | Copper |
| Conductor Stranding | Stranded |
| Connector 1 | (1) RJ-45 Male(1) RJ-45 Male |
| Connector 2 | (1) RJ-45 Male(1) RJ-45 Male |
| Connector Hood Material | PVC |
| Connector Type | BootedSnagless |
| Jacket Rating | Standard / Non-Rated |
| Product Type | Cable |
| UPC | 757120003892 |
| Certifications | CENDAA 889Prop 65REACHRoHSTSCA |
| Jacket Material | PVC |
| Warranty | Lifetime |
Resources
You'll need these with it
8 Port Cat5e Network Interface Module
AC1058$54.99
Cat5e Quick Connect RJ45 Keystone Insert in Green
WP3475GN$3.99
Cat5e Keyed RJ45 Keystone Connector in Black
WP3458BK$6.49
Cat5e RJ45 Keystone Connector in Orange
WP3450OR$4.49
6-Port Network Interface Module
AC1000$54.99
Trio Combo Module with Cat5e Data
CO1156$109.99
Cat5e Quick Connect RJ45 Keystone Insert in Brown
WP3475BR$3.99
Cat5e RJ45 Keystone Connector in Gray
WP3450GY$4.49
6-Port Cat5e Network Interface Module
AC1012$59.99
RJ45 Cat-5E Insert in White - 5 Pack
F3450WHV5$22.99
Cat5e RJ45 Keystone Connector in Brown
WP3450BR$4.49
Cat5e Quick Connect RJ45 Keystone Insert in Ivory
WP3475IV$3.99
Questions about this part
Will this Cat5e cable work with my network switch or router?
Yes, this C2G CG00389 cable features standard RJ-45 male connectors and is compatible with any device using standard Ethernet connections.
What is the difference between this and the other C2G Cat5e cables?
This SKU is the 20ft Gray version; the C2G Cat5e Snagless Series is available in various other colors and lengths up to 150ft.
Is this cable suitable for high-bandwidth video distribution?
Yes, this Cat5e cable is specifically designed for fast Ethernet networks requiring bandwidth-intensive video or data distribution.
Does the snagless boot design prevent damage during installation?
Yes, the molded snagless boot protects the RJ-45 clips from snags and provides extra strain relief during installation and frequent use.
What certifications does this patch cable hold?
The CG00389 is NDAA 889 compliant and carries CE, REACH, RoHS, and TSCA certifications.
