Universal Flat Panel Mount Hardware kit-FHB5196
Hardware kit with M8 screws and 4" vertical offset adapter brackets for large format display alignment
The FHB5196 is a specialized hardware kit used to fasten and align large format displays with high or low VESA hole patterns to Chief mounts. This kit is a bundled solution that combines the FHB5147 M8 screw kit with the FHB5149 offset adapter within a single package. It is specifically designed to assist with displays that have a vertical VESA pattern of up to 405 mm. This kit includes various lengths of M8 screws and spacers required to accommodate a wide range of large format displays, such as the Samsung QMR, QBR, QHR, QET, and QBN series. It is important to note that this kit is compatible only with Chief mounts equipped with flat interface brackets; it is not compatible with mounts that utilize mounting buttons. This TAA compliant accessory type is rated for outdoor use.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
| Shipping Dimensions | 20" x 10.5" x 4.5"(508 x 266.7 x 114.3 mm) |
| Shipping Weight | 4.02 lbs (1.8 kg) |
| Accessory Type | Interface BracketsMounting Hardware |
| Color | Black |
| Solution Type | Universal and Custom |
| Special Features | Outdoor Use |
| TAA Compliant | Yes |
| UPC | 841872175911 |
| Certifications | TAA |
Resources
Verified fitment
Questions about this part
Will the FHB5196 work with my Chief mount?
This kit is designed for use with Chief mounts that feature flat interface brackets. It is not compatible with any Chief mounts that use mounting buttons.
What VESA pattern can the FHB5196 handle?
The FHB5196 is designed to accommodate displays with a vertical VESA pattern of up to 405 mm.
Is the FHB5196 a standalone screw kit?
No, this is a bundled solution that includes both the FHB5149 offset adapter and the FHB5147 M8 screw kit.
What specific Samsung displays are compatible?
The kit is designed for use with series such as the Samsung QMR, QBR, QHR, QET, and QBN, and is verified against models like the Samsung QB43B, QB43N, QB43R, and QB43RB.
Which documents are available for the FHB5196 installation?
Installers can refer to the FHB5147 Installation Manual or the FHB5149 Installation Guide for specific assembly instructions.
