UCP Module without DB25 Punchout
Single-capacity aluminum UCP module with a brushed and anodized finish for UCP Series modular panels
The Middle Atlantic 1DB25 is a single-capacity UCP Module designed for use within various UCP Series modular hardware. This specific module is provided without the DB25 punchout. It features an aluminum construction with a black brushed and anodized finish for a professional appearance in signal routing environments. This module is intended to be installed into one of several compatible Middle Atlantic systems, including the UCP Series Chassis, the UCP Series Hinged Frame Kit, or the UCP Series Cable Tray. It is also compatible with the FK2 and FK4 Series Frame Kits. This product is TAA compliant.
No documents are published for this part. Ask us for the paperwork and we will get it from the manufacturer.Key features
Specifications
| Depth | 0.13 in (0.3 cm) |
| Height | 3.49 in (8.9 cm) |
| Shipping Weight | 0.13 lbs (0.1 kg) |
| Width | 3.39 in (8.6 cm) |
| Base Series | FK2, FK4, UCP-CH, UCP-CT, or UCP-SF |
| Finish | Brushed and Anodized |
| UCP Module Capacity | 1 |
| UPC | 656747000164 |
You'll need these with it
Questions about this part
What series is this module compatible with?
The 1DB25 fits into the UCP Series Chassis (UCP-CH), the UCP Series Hinged Frame Kit (UCP-SF), the UCP Series Cable Tray (UCP-CT), and the FK2 or FK4 Series Frame Kits.
Is this module a complete connector solution?
No, the 1DB25 is a UCP Module provided without the DB25 punchout.
Does this product meet TAA requirements?
Yes, this 1DB25 module is TAA compliant.
What is the finish of the 1DB25 module?
The module features a black brushed and anodized finish on an aluminum construction.
