RPA Universal Projector Kit (RPAUW, CMS0203W, CMS115W)
Universal white ceiling projector mount kit with an adjustable 2' - 3' extension column and Speed-Connect ceiling plate
The KITPD0203W is a preconfigured white projector ceiling mount kit designed to simplify the ordering and installation process for professional AV integrators. This universal solution includes the RPAUW Universal Projector Mount, which provides independent roll, pitch, and yaw adjustability to ensure precise projector positioning. The kit is paired with a CMS0203W adjustable extension column, providing a column length of 2' - 3" (0.61m - 0.92m) to accommodate various ceiling heights. For simplified mounting, the kit includes a CMS115W ceiling plate featuring Chief's Speed-Connect technology. This TAA compliant assembly supports a total weight capacity of 50 lbs (22.7 kg), making it a reliable choice for standard ceiling-mounted projector installations. By combining these specific components—the RPAUW, CMS0203W, and CMS115W—into a single SKU, installers can ensure all necessary mounting hardware is compatible and ready for deployment on-site.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Column Length | 2' - 3' (0.61m - 0.92m) |
| Extension | 24" - 36" (60.96cm - 91.44cm) |
| Shipping Dimensions | 32" x 14.5" x 5" (812.8 x 368.3 x 127 mm) |
| Shipping Weight | 14.64 lbs (6.6 kg) |
| Weight Capacity | 50 lbs (22.7 kg) |
| Adjustability | Independent Roll-Pitch-Yaw |
| Application | Ceiling |
| Ceiling Plate Type | Speed-Connect |
All other specifications 10
| Color | White |
| Column Color | White |
| Column Type | Adjustable |
| Keyed Locking | No |
| Solution Type | Universal |
| Special Features | Kits |
| TAA Compliant | Yes |
| UPC | 841872118857 |
| Ceiling Plate Color | White |
| Certifications | TAA |
Resources
Questions about this part
What is included in the Chief KITPD0203W kit?
This kit is preconfigured to include one RPAUW Universal Projector Mount, one CMS0203W 2-3' (0.61m - 0.91m) extension column, and one CMS115W ceiling plate.
How much weight can the KITPD0203W support?
This ceiling mount kit has a total weight capacity of 50 lbs (22.7 kg).
Does this projector kit include the ceiling plate?
Yes, the kit includes the CMS115W ceiling plate, which utilizes Chief's Speed-Connect mounting system.
What are the adjustability options for this projector mount?
The RPAUW mount included in this kit allows for independent adjustment of the roll, pitch, and yaw.
Is this projector kit TAA compliant?
Yes, the KITPD0203W is TAA compliant.
