KO Series Rear Door Fan Kit, 190 CFM
Active rear door fan kit for Middle Atlantic WRK, MRK, and ERK series enclosures, providing 190 CFM of airflow via 120 VAC power
The KO-AWFP2 is a rear door fan kit designed to provide active thermal management for Middle Atlantic WRK, MRK, and ERK series enclosures. This kit is intended for use with standard solid rear doors that have been configured by removing the laser knockouts. The kit includes a specialized panel and two fans to facilitate airflow. It operates on 120 VAC input voltage and provides a total airflow of 190 CFM. This component type is an active solution, making it a critical addition for integrators managing heat loads in high-density rack environments. For automated temperature control, this kit is compatible with the FC-4-1CA Thermostatic Fan Controller.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
| CFM | 190 |
| Depth | 2 in (5.1 cm) |
| Height | 5.25 in (13.3 cm) |
| Volts AC | 120 VAC |
| Width | 19 in (48.3 cm) |
| Available Internationally | No |
| Component Type | Active |
| Manufacturer | Middle Atlantic |
| Power Type | AC |
| UPC | 656747060939 |
Resources
You'll need these with it
Questions about this part
Which Middle Atlantic rack series is this fan kit compatible with?
This kit is designed for the WRK, MRK, and ERK series enclosures with standard solid rear doors.
How do I install this fan kit on a solid rear door?
The kit is installed after the laser knockouts have been removed from the rear door of the enclosure.
Can I automate the fan operation?
Yes, this kit is compatible with the FC-4-1CA Thermostatic Fan Controller to manage airflow based on temperature.
What are the power requirements for the KO-AWFP2?
The kit requires a 120 VAC power source to operate the included fans.
What is the airflow capacity of this kit?
The KO-AWFP2 provides a total of 190 CFM of airflow for the enclosure.
