Fusion® Menu Board Ceiling B2B Adapter
Ceiling adapter for Fusion LCM menu boards, enabling back-to-back display configurations for 42"-65" screens
The Chief FMSCB is a specialized adapter used to retrofit single-sided ceiling configurations into full back-to-back menu board solutions. This is a modular add-on accessory designed specifically for the Fusion® LCM Menu Board series, allowing installers to create prominent dual-sided displays in large venue environments where wall space is unavailable. It facilitates 1x1 array configurations for displays ranging from 42" to 65" (1067mm - 1651mm). The adapter features lateral shift capability and supports a weight capacity of 200 lbs (90.7 kg) per configuration. Designed for ceiling applications, this TAA compliant component ensures compatibility for government and high-security projects. Its modular design allows for flexible deployment in complex commercial spaces where signage must be visible from multiple directions.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Depth | 1.6 in (4.1 cm) |
| Height | 8.2 in (20.8 cm) |
| Lateral Shift | Yes |
| Overall Dimensions | 8.2" x 7.0" x 1.6" (208mm x 178mm x 40.64mm) |
| Shipping Weight | 4.8 lbs (2.2 kg) |
| Typical Screen Size | 42" - 65" (1067mm - 1651mm) |
| Weight Capacity | 200 lbs (90.7 kg) |
| Width | 7 in (17.8 cm) |
All other specifications 9
| Accessory Type | ExtensionInstallationMulti-Display |
| Adjustability | Fixed |
| Application | Ceiling |
| Array Configuration | 1x1 |
| Color | Black |
| Special Features | Large VenueModularMulti-Display |
| TAA Compliant | Yes |
| UPC | 841872175805 |
| Certifications | TAA |
Resources
Questions about this part
Will the FMSCB allow me to mount two displays back-to-back on the ceiling?
Yes, this adapter is specifically designed to retrofit single-sided Fusion LCM ceiling configurations into back-to-back solutions.
What display sizes is this adapter compatible with?
The FMSCB is compatible with displays in the 42" to 65" (1067mm - 1651mm) range.
What is the weight capacity for this ceiling adapter?
This accessory supports a weight capacity of 200 lbs (90.7 kg) for your menu board installation.
Does this adapter offer any adjustment for screen alignment?
Yes, the FMSCB includes lateral shift capabilities to assist with precise screen positioning.
Which documents are available for submittals?
You can access the FMSCB Technical Drawing (PDF) and the FMSCB CAD Drawing (dwg) for your project submittals.
