4" vertical offset mounting adapter for displays with non-centered VESA patterns, compatible with Chief Fusion and Thinstall mounts
The Chief FHB5149 is a 4" vertical offset mounting adapter bracket designed to resolve alignment issues for displays with high or low VESA patterns. This interface bracket is specifically intended for use with screens where the VESA pattern is not vertically centered. It is fully compatible with Chief Fusion® and Thinstall™ mounts, provided the mount utilizes flat interface brackets. Please note that this adapter is not compatible with mounts that require the use of mounting buttons. This hardware solution is verified for outdoor use and is TAA compliant. It accommodates displays featuring a vertical VESA pattern of up to 405 mm, ensuring a customized fit for various professional display configurations.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
| Shipping Dimensions | 20" x 10" x 4.5"(508 x 254 x 114.3 mm) |
| Shipping Weight | 2.87 lbs (1.3 kg) |
| Accessory Type | Interface Brackets |
| Color | Black |
| Solution Type | CustomUniversal |
| Special Features | Outdoor Use |
| TAA Compliant | Yes |
| UPC | 841872174617 |
| Certifications | TAA |
Resources
Verified fitment
Questions about this part
Will the FHB5149 work with my Fusion or Thinstall mount?
Yes, it is compatible with Chief Fusion® and Thinstall™ mounts, but only if your mount uses flat interface brackets; it will not work with mounts using mounting buttons.
What is the maximum VESA pattern this offset can handle?
The FHB5149 supports displays that have a vertical VESA pattern measurement of up to 405 mm.
Is this mounting adapter verified to fit my specific display?
The FHB5149 is verified against 657 display models from 18 manufacturers, including LG, Sony, Samsung, Panasonic, and ViewSonic.
What is the purpose of the 4 inch offset?
The 4" vertical offset is used to correct mounting alignment when a screen has a high or low VESA pattern that is not vertically centered.
Which technical documents are available for submittals?
You can access the FHB5149 Installation Guide (PDF), Technical Drawing (PDF), or the CAD Drawing (dwg) for your project submittals.
