Fiber Management Spools Pair
Fiber management spools sold as a pair, featuring a 1.5" radius for maintaining proper bend requirements in structured wiring enclosures
The On-Q AC1041 is a pair of fiber management spools designed to provide organized cable routing within a structured wiring enclosure. These spools feature a half round design and multiple mounting holes, allowing installers to choose between horizontal or vertical installation. The 1.5" spool radius is engineered to maintain the proper bend requirements necessary for both fiber optic and category cabling. Each spool includes 1/2" retention tabs to hold excess fiber, while notched openings allow for securing cables with the included 4" cable ties. This kit is constructed from durable ABS Plastic and comes with (4) plungers and grommets to facilitate installation.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Resources
Questions about this part
How can I mount these fiber management spools?
The half round design and multiple mounting holes allow for both vertical and horizontal installation within your enclosure.
What is the bend radius for the AC1041 spools?
The spools feature a 1.5" radius to help maintain proper bend requirements for both category cable and fiber.
What is included in the AC1041 package?
This product is sold as a pair and includes (2) 4" cable ties, (4) plungers, and grommets.
What is the purpose of the retention tabs on these spools?
The 1/2" retention tabs are designed to contain excess fiber, while notched openings allow you to secure the cable with ties.
Which documents are available for submittals?
You can access the CAD files (PDF and DWG), the installation sheet, or the product sellsheet via the manufacturer documentation.
