DQFP15BK Cord Ended deQuorum™ Single-Flip Up Unit in Black
Black single-flip up table box with a 15 Amp tamper-resistant duplex receptacle and 6 ft cord
The Wiremold DQFP15BK is a deQuorum Single-Flip Up Unit finished in a black powder coat. This furniture power solution is designed for conference rooms, meeting rooms, and office environments where a low-profile, slim design is required to integrate into table surfaces. It features one 15 Amp black tamper-resistant duplex receptacle, utilizing a patented shutter system to prevent the insertion of foreign objects. The unit includes a 6 ft (1.83 m) cord for connection to a power source. This model is cULus listed, meeting both US and Canadian safety standards for Relocatable Power Taps and Multioutlet Assemblies. The soft opening cover mechanism provides a quieter, more professional tactile feel during operation. For submittal planning, installers can refer to the deQuorum Flip-Up Table Boxes PDF or the Div 16 and Div 26 documentation for electrical system integration.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
| Amps | 15 Amp |
| Color | Black |
| TAA Compliant | No |
| USB Port | No |
| Warranty | 1-Year from Installation or 2-Years from Day of Sale |
| Cord Length | 6 ft |
Resources
Questions about this part
Does this unit include USB charging ports?
No, this specific DQFP15BK model is equipped with a 15 Amp duplex receptacle but does not include USB ports.
What is the cord length for the DQFP15BK?
The unit comes equipped with a 6 ft (1.83 m) cord for power connection.
Is the DQFP15BK suitable for environments where liquid spills might occur?
Yes, it meets and exceeds the UL1363 standard for relocatable power taps to help protect against moisture entry.
What is the difference between this unit and the stainless steel version?
The DQFP15BK features a black powder coat finish, whereas the series also offers a brushed stainless steel finish option.
Which documents are available for electrical submittals?
Installers can use the deQuorum Flip-Up Table Boxes PDF or the Div 16 and Div 26 DOCX files for system integration and submittals.
