ConnexSys™ Video Wall Strut Channel 60 Inch
60 inch pre-painted black strut channel for ConnexSys video wall mounting and row leveling
The Chief CSAS060 is a 60 in (152.4 cm) pre-painted black strut channel designed for use within the ConnexSys™ Video Wall Mounting System. This accessory facilitates the efficient installation of multi-display configurations by allowing installers to hang units on a single strut channel to achieve rapid row leveling. By using this channel, the need for horizontal spacers is eliminated, which reduces total installation time, particularly during complex recessed or extra-large video wall configurations. This 60 in (152.4 cm) component functions as the equivalent of standard 1-5/8" x 13/16" channel strut. Its 1.65 in (4.2 cm) width and 0.84 in (2.1 cm) depth allow for precise alignment of multiple display rows in menu board or video wall applications. This SKU is part of a series that includes 72 in and 90 in length options.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Depth | 0.84 in (2.1 cm) |
| Height | 60 in (152.4 cm) |
| Length | 60 in (152.4 cm) |
| Overall Dimensions | 60 x 1.65 x 0.84" (1524 x 42 x 21 mm) |
| Shipping Weight | 11 lbs (5 kg) |
| Width | 1.65 in (4.2 cm) |
| Accessory Type | InstallationLateral ShiftMulti-Display |
| Adjustability | Lateral Shift |
All other specifications 6
| Application | Wall |
| Color | Black |
| Special Features | Multi-Display |
| TAA Compliant | Yes |
| UPC | 841872169194 |
| Certifications | TAA |
Questions about this part
Will the CSAS060 help with video wall alignment?
Yes, the CSAS060 allows you to hang units on a single strut channel for quick row leveling in multi-display installations.
Is this the only length available in the ConnexSys strut series?
No, the CSAS060 is the 60 in (152.4 cm) version; the series also includes 72 in and 90 in pre-cut lengths.
What is the difference between this and standard channel strut?
The CSAS060 provides dimensions equivalent to most 1-5/8" x 13/16" sizes of standard channel strut.
What do I need to buy to complete my ConnexSys video wall?
The CSAS060 is an accessory used with the ConnexSys™ Video Wall Mounting System to assist with lateral shift and installation.
Is the CSAS060 TAA compliant?
Yes, the CSAS060 is TAA compliant for use in regulated environments.
