CMA347, Vibration Isolating Coupler
Vibration isolating coupler for ceiling applications, connects two extension columns to reduce image movement in large venue installs
The Chief CMA347 is a vibration isolating coupler designed for ceiling-mounted projector systems. This component connects two extension columns together to isolate the system from vibrations that might otherwise travel through the lower column and cause image movement. It is specifically engineered for large venue environments where stability is critical. This coupler is compatible with Chief CMS columns featuring a 1.5” NPT connection. When calculating total system weight, installers must include the weight of everything below the vibration isolator, such as the column, the projector mount, and the projector itself. The total weight of the assembly beneath this coupler must remain under 35lbs (15.87 kg). For custom mounting configurations, please refer to Chief's MountFinder™ tool to ensure compatibility.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
| Depth | 30.9 in (78.5 cm) |
| Height | 5.2 in (13.2 cm) |
| Overall Dimensions | 5.2" x 27.4" x 30.9" (132 x 695 x 784 mm) |
| Shipping Weight | 23 lbs (10.4 kg) |
| Weight Capacity | Under 35lbs |
| Width | 27.4 in (69.6 cm) |
| Accessory Type | ExtensionPower |
| Application | Ceiling |
| Color | Black |
| Special Features | Vibration Dampening |
| TAA Compliant | No |
| UPC | 841872018584 |
Resources
Questions about this part
Will the CMA347 work with my Chief CMS column?
The CMA347 is compatible with Chief CMS columns that feature a 1.5” NPT connection.
How much weight can I hang below the CMA347 coupler?
The total weight capacity is under 35lbs (15.87 kg), and this includes the weight of the projector, the mount, and the column below the isolator.
What is the purpose of using this vibration isolating coupler?
It uses a patented design to isolate vibrations transmitted to the lower column, which helps reduce movement in the projected image.
What do I need to do to ensure my custom mount is compatible?
You should use the Chief MountFinder™ tool to verify that your custom mounting setup is compatible with this coupler.
What documents are available for submittals?
Technical drawings, CAD drawings in .dwg format, and the installation manual are all available for this product.
