660 CFM Fan Top
Integrated fan top with two 6" fans, 660 CFM airflow, and a removable service plate for WR and MRK series racks
The Middle Atlantic MW-6FT-660CFM is an active, pre-assembled fan top designed to provide thermal management for professional rack enclosures. This unit delivers 660 CFM of airflow through two 6" fans and includes fan guards to protect the components. It is engineered for compatibility with WR, WRK, MRK, VRK, VMRK, and DRK series racks. For easier maintenance, the assembly features a removable two-space service plate, which allows technicians to remove the top for service without disrupting existing cable bundles. Constructed from steel with a black finish, this component operates on 120 VAC and is TAA compliant.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
| CFM | 660 |
| Height | 25.06 in (63.7 cm) |
| Shipping Weight | 17 lbs (7.7 kg) |
| Volts AC | 120 VAC |
| Width | 21.7 in (55.1 cm) |
| Color | Black |
| Component Type | Active |
| Controlled | No |
| Manufacturer | Middle Atlantic |
| Material | Steel |
| Power Type | AC |
| UPC | 656747093579 |
You'll need these with it
Questions about this part
Which rack series is the MW-6FT-660CFM compatible with?
This fan top fits WR, WRK, MRK, VRK, VMRK, and DRK series racks.
Can I service the top without moving my cables?
Yes, the included removable two-space service plate allows for top removal without disrupting installed cable bundles.
What is the airflow capacity of this fan top?
The MW-6FT-660CFM provides a total of 660 CFM airflow.
What else do I need to control the fans?
You can add a Stand Alone Thermostatic Fan Controller, such as the FC-2-215-1CA or FC-4-1CA, to manage fan operation.
Is this product TAA compliant?
Yes, the MW-6FT-660CFM is TAA compliant.
