6 Inch (152 mm) Ceiling Plate with Adjustable Column in White
White 6-inch ceiling plate and adjustable extension column with 12" to 18" travel and 500 lbs capacity
The Chief CMA700W provides a complete structural ceiling installation solution in a white finish. This kit features a 6 in (15.2 cm) square ceiling plate paired with an adjustable extension column that offers a range of 12" to 18" (305–457 mm) to accommodate specific mounting heights. Designed for high-capacity professional environments, the assembly supports a weight capacity of 500 lbs (226.8 kg). The system utilizes a 1.5" NPT connection for mounting. This white variant is part of the Chief Ceiling Plate with Adjustable Column series, providing a clean aesthetic for white-painted ceilings or bright environments. For technical submittals, installers can reference the CMA700 CAD drawing or the CMA700 technical drawing available in the resources section.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Ceiling Plate Size | 6 in (15.2 cm) |
| Depth | 6 in (15.2 cm) |
| Extension | 12" - 18" (30.48cm - 45.72cm) |
| Height | 18 in (45.7 cm) |
| Overall Dimensions | 18.0" x 6.0" x 6.0" (457 x 152 x 152 mm) |
| Shipping Weight | 8 lbs (3.6 kg) |
| Weight Capacity | 500 lbs (226.8 kg) |
| Width | 6 in (15.2 cm) |
All other specifications 5
| Accessory Type | Ceiling Plates and Adapters |
| Color | White |
| TAA Compliant | Yes |
| UPC | 841872045436 |
| Certifications | TAA |
Resources
Questions about this part
Will the CMA700W fit my ceiling installation requirements?
This kit includes a 6 in (15.2 cm) square ceiling plate and an extension column that adjusts between 12" and 18" (305–457 mm).
What is the weight limit for the CMA700W white ceiling plate kit?
The CMA700W is rated for a weight capacity of 500 lbs (226.8 kg).
Does the CMA700W require specific mounting hardware for the ceiling?
The unit utilizes a 1.5" NPT connection for the structural ceiling installation.
What is the difference between the CMA700W and other CMA series columns?
The CMA700W is the white finish version of this series; the CMA700B is the black version.
Where can I find CAD drawings for the CMA700W?
A CMA700W CAD drawing in .dwg format is available in the resources tab for submittals.
