5'-6’ Outdoor Column
Outdoor column extension providing 12" of adjustable height for ceiling or floor installations
The ODAC0506B is an outdoor-rated column extension designed to integrate with Chief OLC Outdoor Ceiling Mounts. This extension provides a 12" adjustment range, allowing installers to set the height in 1" increments between 57" and 72" (1448–1828 mm) for both floor and ceiling applications. Engineered to withstand harsh environments, the column is built to endure rain, humidity, ocean air, sun exposure, and high winds. The construction features UV-rated plastics, stainless-steel hardware, and corrosion-resistant paint to meet UL 2442 Part 2 standards. When subjected to extreme wind loads, the system is engineered to flex to mitigate catastrophic damage to the facility. This column is specifically designed for use with Chief outdoor-rated mounts and plates only.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Length | 65.75 in (167 cm) |
| Shipping Dimensions | 66.75" x 4" x 3.5" (169.6 x 10.2 x 8.9 cm) |
| Shipping Weight | 21.1 lbs (9.6 kg) |
| Weight Capacity | 300 lbs (136 kg) |
| Accessory Type | Extension |
| Adjustability | 5' - 6' (1.52 - 1.83m) |
| Adjustments | 57" - 72" (1448mm - 1828 mm) |
| Application | CeilingFloor |
All other specifications 5
| Color | Black |
| Special Features | Outdoor Use |
| TAA Compliant | Yes |
| UPC | 841872172880 |
| Certifications | TAAUL Listed |
Resources
Questions about this part
What displays can I use this column with?
This is an accessory column and only works with Chief outdoor-rated mounts and plates.
How much height adjustment does the ODAC0506B provide?
The column provides a 12" range of adjustment, allowing you to set the height in 1" increments between 57" and 72".
Is this column suitable for coastal environments?
Yes, it is built to withstand ocean air, high winds, and humidity using UV-rated plastics, stainless-steel hardware, and corrosion-resistant paint.
Can this column be used for both floor and ceiling mounts?
Yes, the ODAC0506B is designed for both ceiling and floor applications.
Which document do I need for a submittal?
The ODAC0XXX Technical Drawing (PDF) is available for technical submittals and planning.
