4'-5’ Outdoor Column
Outdoor column extension for ceiling or floor applications with a 4' to 5' adjustment range and 300 lbs capacity
The Chief ODAC0405B is an outdoor-rated column extension designed for ceiling or floor installations. This 4' - 5' (1.22 - 1.52m) extension provides 12" of adjustment range, allowing for precise positioning in 1" increments during ceiling installations. To ensure durability in harsh environments, the column features a weatherproof design that meets UL 2442 Part 2 standards, utilizing stainless-steel hardware, UV-rated plastics, and corrosion-resistant paint to withstand humidity, ocean air, sun exposure, and rain. The unit is rated for a weight capacity of 300 lbs (136 kg) and is wind-compatible to a maximum moment force of 2000 ft-lbs. This column is intended to work exclusively with Chief outdoor-rated mounts and plates.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Length | 53.75 in (136.5 cm) |
| Shipping Dimensions | 54.75" x 4" x 3.5" (139.1 x 10.2 x 8.9 cm) |
| Shipping Weight | 17.1 lbs (7.8 kg) |
| Weight Capacity | 300 lbs (136 kg) |
| Accessory Type | Extension |
| Adjustability | 4' - 5' (1.22 - 1.52m) |
| Adjustments | 45"- 60" (1143mm - 1524 mm) |
| Application | CeilingFloor |
All other specifications 5
| Color | Black |
| Special Features | Outdoor Use |
| TAA Compliant | Yes |
| UPC | 841872171906 |
| Certifications | TAAUL Listed |
Resources
Questions about this part
Will the ODAC0405B work with my existing outdoor mount?
This column only works with Chief outdoor-rated mounts and plates. It is designed specifically to integrate with the OLC Outdoor Ceiling Mounts series.
How much can I adjust the length of this column?
The ODAC0405B offers an adjustment range of 4' - 5' (121.9 – 152.4 cm), providing 12" of travel in 1" increments for ceiling installations.
Is this column suitable for coastal environments?
Yes, the weatherproof design is built to withstand rain, humidity, and ocean air through the use of corrosion-resistant paint, UV-rated plastics, and stainless-steel hardware.
What is the maximum weight capacity for the ODAC0405B?
The column has a weight capacity of 300 lbs (136 kg) and is wind-compatible up to a 2000 ft-lbs maximum moment force.
Where can I find technical drawings for this extension?
You can access the ODAC0XXX Technical Drawing (PDF) or the CAD Drawing (dwg) via the Resources tab for submittals.
