10x8 Combo Module RJ45 with RJ31X
Multimedia combo module distributing 4 telephone lines to 10 locations and 1 GHz video to 8 locations
The On-Q CO1045 is a specialized combo module designed to consolidate telecommunications and video distribution within a single footprint. This unit distributes up to 4 incoming telephone lines across 10 RJ45 locations and manages 1 GHz video across 8 locations using an integrated 8-way passive digital HDTV cable splitter. To assist with installation in tight enclosures, the mounting bracket features a detachable platform for the coax splitter. This design allows installers to access all termination ports easily during the initial setup before securing the platform to maintain a compact form factor. For added security, the module includes an RJ31X security line interface and provides 6 kV ring wave surge protection on all coax ports.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
| Color | Black |
| Number of Ports | 10 |
Resources
Questions about this part
How many video locations does this module support?
The module provides 1 GHz video distribution to 8 locations via an integrated passive splitter.
Does this module include security features for telephone lines?
Yes, this combo module includes an RJ31X security line interface for telecom protection.
What kind of surge protection is included for the coax ports?
All coax ports on this module feature 6 kV ring wave surge protection.
How does the mounting bracket assist with installation?
The bracket includes a detachable platform for the coax splitter, allowing for easier access to termination ports during installation.
Is this module used for 4-line or 1-line telephone distribution?
The CO1045 is a 1x10 4-line RJ45 telecom module.
