Vertical Rackmount System
Vertical rackmount shelf holding up to 6 satellite or cable boxes, 35 lbs capacity, 19-inch width
The Middle Atlantic VRS is a space-saving Vertical Rackmount System designed to optimize rack efficiency by mounting multiple video sources vertically. This system eliminates the need for several individual horizontal shelves by housing up to 6 satellite or cable boxes within a single 3.5 in (8.9 cm) high unit. With a 19 in (48.3 cm) width and a 15.38 in (39.1 cm) depth, it provides a 15 in (38.1 cm) usable depth to accommodate most popular box sizes. This TAA compliant solution is particularly effective for high-density installations in sports bars, gyms, or hotels where multiple sources are required. For organized cable management, use this shelf with SignalSAFE™ IEC cords. The VRS is also compatible with the PD815SC-PBSH power strip, which mounts conveniently to the rear edge of the system.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
| Depth | 15.38 in (39.1 cm) |
| Height | 3.5 in (8.9 cm) |
| Usable Depth | 15 in (38.1 cm) |
| Weight Capacity | 35 lbs (15.9 kg) |
| Width | 19 in (48.3 cm) |
| Cable Box Capacity | 6 |
| UPC | 656747115028 |
Resources
You'll need these with it
Questions about this part
How many devices can the Middle Atlantic VRS hold?
This system is designed to mount up to 6 satellite or cable boxes vertically, reducing the total number of individual shelves required in your rack.
Will this shelf work with the PD815SC-PBSH power strip?
Yes, the VRS is compatible with the PD815SC-PBSH 8-outlet, 15A surge protection power strip, which mounts directly to the rear edge of the shelf.
What is the weight capacity and usable depth of the VRS?
The system has a weight capacity of 35 lbs (15.9 kg) and offers a usable depth of 15 in (38.1 cm).
Is the Middle Atlantic VRS TAA compliant?
Yes, the VRS is a TAA compliant product, making it suitable for specific procurement requirements.
What are the dimensions of this vertical rack shelf?
The VRS measures 19 in (48.3 cm) wide, 3.5 in (8.9 cm) high, and 15.38 in (39.1 cm) deep.
