Select Series PDT Low Profile Vertical Power Strip with Dual Circuit, 6 Outlet, 20A Hardwired
Vertical 6-outlet power strip with dual 20A hardwired circuits and a low-profile 2.58" width
The Middle Atlantic PDT-2X320 is a low-profile vertical power strip designed to maximize available rack space while meeting high-demand electrical requirements. This Select Series unit features dual circuits, allowing installers to distribute power loads effectively across two 20 Amp paths. With a slim chassis width of 2.58" (6.6 cm) and a depth of 2.1" (5.3 cm), this 30" (76.2 cm) tall strip mounts unobtrusively in the back of a rack, placing outlets in close proximity to the equipment they serve. This model utilizes a J-Box plug type for hard-wired power cable termination. It is designed to mount to all styles of Middle Atlantic rack rail brackets using the included mounting hardware, which allows the unit to snap into place quickly for efficient installation.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
Main specifications 8
| Amps | 20 Amp |
| Depth | 2.1 in (5.3 cm) |
| Height | 30 in (76.2 cm) |
| Shipping Weight | 5 lbs (2.3 kg) |
| Volts AC | 120 VAC |
| Width | 2.58 in (6.6 cm) |
| Cable Type | Hard-Wired |
| Finish | Black Anodized |
All other specifications 6
| Local Meter | No |
| Number of Circuits | 2 |
| Outlet Count | 6 |
| Plug Type | J-Box |
| UPC | 656747191701 |
| Certifications | ETL Listed |
Resources
Questions about this part
Will the PDT-2X320 fit in my existing Middle Atlantic rack?
Yes, this unit is designed to mount to every style of Middle Atlantic rack rail brackets using the included mounting hardware.
How is the power cable connected to the PDT-2X320?
This is a hard-wired model that utilizes a J-Box plug type for power cable termination.
What is the difference between this and the single circuit models?
The PDT-2X320 features dual circuits, providing two separate 20 Amp paths to handle higher electrical demands from multiple equipment pieces.
What do I need to do to install this vertical strip?
The PDT series includes the necessary mounting hardware to snap the PDU into place, making the installation process a quick, one-step task.
Which documentation is available for submittals?
You can download the PDT Series instruction sheet, technical specification drawings, or the full PDT Series A&E specification sheet from the resources tab.
