RPSFB Ratchet-Pro™ Steel Concrete Floor Box
Steel concrete floor box for 4'' to 6'' thick pours, compatible with 2HUB conduit feeds for increased capacity
The RPSFB Ratchet-Pro™ Steel Concrete Floor Box is a rectangular, dual-service metal enclosure designed for above-grade installations. It features a nonmetallic top that facilitates concrete pours between 4'' thick and 6'' thick. To assist during installation, the box includes graduated markings on both the interior and exterior to indicate volume capacity and the specific depth of the concrete pour. For installers requiring higher capacity, the RPSFB is compatible with the 2HUB to allow for 2'' conduit feeds, which can be purchased separately. The design includes a streamlined divider that can be easily cut with a utility knife to create room for wire splicing. For ongoing protection, RP Series Covers provide "Dead-Front" protection, with slide covers that snap back into place when the receptacle is not in use to keep debris out.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
| Grade Type | Above Grade |
| TAA Compliant | Yes |
| Certifications | TAA |
| Warranty | 1-Year from Installation or 2-Years from Day of Sale |
Resources
Questions about this part
How much concrete depth does the RPSFB support?
This box is designed for concrete pours ranging from 4'' thick to 6'' thick, with graduated markings to assist with depth accuracy.
What is required to increase the conduit feed size?
You can use a 2HUB, sold separately, to allow for 2'' conduit feeds and increase the capacity for preterminated cables.
Which covers are compatible with this floor box?
The RPSFB uses RP Series Covers, which feature slide covers that snap back into place to protect against dirt and debris.
What tools are needed for installing the internal divider?
The streamlined divider is designed to be cut using a utility knife, eliminating the need for a hacksaw or tape measure.
Is this product TAA compliant?
Yes, the RPSFB is TAA compliant for projects requiring compliance with the Trade Agreements Act.
