RC9CM2TCGY Single Service Furniture Feed Poke-Thru Device Cover Assembly in Gray
Gray single-service furniture-feed poke-thru cover assembly for tile or carpet installations
The Wiremold RC9CM2TCGY is a single-service furniture-feed poke-thru device cover assembly finished in gray. This assembly features a combination of 1 1/4'' and 2'' trade size threaded conduit openings equipped with closure plugs. To maintain the necessary fire classification, this unit must be used with a conduit connector at the adapter assembly plate, which is not included. It is assembled with a scrub water gasket to protect the installation. This component is intended for use on floor coverings with a minimum thickness of 1/8'', specifically on tile or carpet floors. Note that this device is not designed for installation in bare concrete or terrazzo. Installation requires a 3'' (76mm) diameter hole. This SKU is part of the RC9AM2TC Series and is available in black (BK) and brushed aluminum (AL) finishes as well.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
| Color | Gray |
| TAA Compliant | Yes |
| Certifications | TAA |
| Warranty | 1-Year from Installation or 2-Years from Day of Sale |
Resources
Questions about this part
What is the required hole size for the RC9CM2TCGY?
The RC9AM2TC Series requires a 3'' (76mm) diameter hole for installation.
Can this poke-thru be installed in concrete floors?
No, this device is not designed for use with bare concrete or terrazzo.
What additional parts are needed to maintain fire rating?
You must use a conduit connector (not included) at the adapter assembly plate to maintain the fire classification.
Will this work on carpeted floors?
Yes, it is designed for use on carpet or tile floors with a minimum thickness of 1/8''.
Are there other color options for this series?
The finish flange/cover assembly is also available in black (BK) and brushed aluminum (AL).
