RC9CM2TCBK Single Service Furniture Feed Poke-Thru Device Cover Assembly in Black
Black furniture-feed poke-thru cover assembly for tile or carpet applications requiring a 3" (76mm) diameter hole
The RC9CM2TCBK is a single-service furniture-feed poke-thru device cover assembly in a black finish. This assembly is designed for use on tile or carpet floors with a minimum thickness of 1/8''. It is specifically engineered to work with RC9AM2TC Series poke-thru devices that require a 3" (76mm) diameter hole. To maintain required fire classification, this unit must be used with a conduit connector at the adapter assembly plate, which is not included with this assembly. This assembly comes equipped with a scrub water gasket and features both 1 1/4'' and 2'' trade size threaded conduit openings with closure plugs. Note that this device is not designed for installation on bare concrete or terrazzo surfaces.
Specifications are supplied by the manufacturer. For complete details, check the Resources section.Key features
Specifications
| Color | Black |
| TAA Compliant | Yes |
| Certifications | TAA |
| Warranty | 1-Year from Installation or 2-Years from Day of Sale |
Resources
Questions about this part
What diameter hole is required for the RC9CM2TCBK?
This assembly is designed for use with RC9AM2TC Series poke-thru devices that require a 3" (76mm) diameter hole.
What flooring types can I use with this device?
It is intended for use on tile or carpet floors with a minimum thickness of 1/8''. It is not designed for bare concrete or terrazzo.
Does this assembly include the conduit connector?
No, a conduit connector is not included. You must use a conduit connector at the adapter assembly plate to maintain fire classification.
What is the difference between the RC9CM2TCBK and other finishes?
This SKU is the black (BK) finish; other available finishes in this series include gray (GY) and brushed aluminum (AL).
What documents are available for submittals?
You can refer to the Furniture Feed Poke-Thru Devices Div 16 or Div 26 documents for technical details.
